RGH 2 Bad Block while dumping nand remapped , safe to continue ???

F

fokeiro

Senior Member
Feb 1, 2010
125
0
MIAMI, FLORIDA
im trying to dump this nand for a jasper and im getting 2 bad blocks, seems J-R is remapping them as per 360 Falsh Dump Tool v0.97, am i safe to continue with RGH process ? i double check soldering (im using pins and check with a magnifying glass for bridging) and seems ok no bridging anywhere....ill post some pics ans J-R log maybe anyone can advice.


Flash dump tool v0.97, they seems similar but jrunner keep saying they diferent but doesnt show where






tried this tool and got this





install












J-R log

===================================================Tuesday, August 12, 2014 9:35:14 PM


J-Runner v0.3 Beta (4) Started






Checking Files
Finished Checking Files
Version: 10
Flash Config: 0x00023010
00023010
Trinity, Jasper 16MB
CB Version: 6754
Jasper 16MB
Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump1.bin
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump2.bin
Initializing nanddump1.bin..
Jasper 16MB
Jtag Selected
Nand Initialization Finished
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump3.bin
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Reading Nand
0x0372
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump4.bin
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Initializing nanddump1.bin..
Jasper 16MB
Nand Initialization Finished
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
0x0372
Initializing nanddump1.bin..
Jasper 16MB
Nand Initialization Finished
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Initializing nanddump1.bin..
Jasper 16MB
Nand Initialization Finished
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Initializing nanddump3.bin..
Jasper 16MB
Nand Initialization Finished
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Initializing nanddump1.bin..
Jasper 16MB
Nand Initialization Finished
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
0x0372
Version: 10
Flash Config: 0x00023010
00023010
Trinity, Jasper 16MB
CB Version: 6754
Jasper 16MB
Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump1.bin
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Initializing nanddump1.bin..
Jasper 16MB
Nand Initialization Finished
Version: 10
Flash Config: 0x00023010
00023010
Trinity, Jasper 16MB
CB Version: 6754
Jasper 16MB
Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump1.bin
Cancelled
Version: 10
Flash Config: 0x00023010
00023010
Trinity, Jasper 16MB
CB Version: 6754
Jasper 16MB
Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump1.bin
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump2.bin
Initializing nanddump1.bin..
Jasper 16MB
Nand Initialization Finished
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
0x0372
Retail Selected
Initializing nanddump1.bin..
Jasper 16MB
Jtag Selected
Nand Initialization Finished
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Click to expand...


Attachments

Last edited:
F

fokeiro

Senior Member
Feb 1, 2010
125
0
MIAMI, FLORIDA
don't continue redo your soldering and try again
Click to expand...
and jrunner doesn't recognize block 372 as remapped but the other app does, ill try to resolder and see


update: desodlered everything and soldered back and got same 2 bad blocks 2BD and 372 but now it says nands are the same, so im good to go then ?

Initializing nanddump1.bin..Jasper 16MB
Nand Initialization Finished
Version: 10
Flash Config: 0x00023010
00023010
Trinity, Jasper 16MB
CB Version: 6754
Jasper 16MB
Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump1.bin
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Reading Nand to C:\Users\Sig\Desktop\xbox rgh\J-Runner\output\nanddump2.bin
Initializing nanddump1.bin..
Jasper 16MB
Nand Initialization Finished
Reading Nand
Error: 250 reading block 2BD
Error: 250 reading block 372
Done!
in 3:24 min:sec


Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Nands are the same
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Nands are the same
Comparing...
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Bad Block ID 02BD Found @ 0x03FF [Offset: 0x107BE00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 02BD [Offset: 0xB4BA00]
Bad Blocks Remapped
Nands are the same
Click to expand...

Last edited:
F

fokeiro

Senior Member
Feb 1, 2010
125
0
MIAMI, FLORIDA
Yes looks good to go, jrunner has remapped nands and are the same.
Click to expand...
thank you ill continue and post results


one last question so i dont haver to create a new thread, for doing coronas once i attach the postfix adapter what do i use to put heatsink back, same xclamp or screws and washers ?

Last edited:
N

N.E.Modz

VIP Member
Sep 27, 2009
2,285
68
A.K.A daleh43
fokeiro said:
thank you ill continue and post results


one last question so i dont haver to create a new thread, for doing coronas once i attach the postfix adapter what do i use to put heatsink back, same xclamp or screws and washers ?
Click to expand...
i always repaste with thermal compound and put xclamps back on

  • Like
Reactions: fokeiro
F

fokeiro

Senior Member
Feb 1, 2010
125
0
MIAMI, FLORIDA
i always repaste with thermal compound and put xclamps back on
Click to expand...
sorry one last question and ill leave yo guys alone for Xbox360 E slim V5/V6 can i use these items

Cool-runner rev c + TX Corona QSB CR Upgrade + postifx adapter and the r/w sd card kit ?

i know CR revc doesnt have the Osc but everything else is out of stock everywhere could only find these to ship to US
