ANSWERED Can Accidentally moving one of the small resistor cause a red dot no boot???

[MeAnRG]

Ok so i was putting a little soilder on the R3B15 point an noticed one of the little resitors moved i put it back in place it was R3B19 that got moved did not attempt to giltch yet an did not write the ecc to the nand yet but wanted to make sure it was fine an greeted with the red dot......:facepalm::facepalm::frown:


http://i1211.photobucket.com/albums/cc433/legitmod/P7080101.jpg



[mespo365]

Ok so i was putting a little soilder on the R3B15 point an noticed one of the little resitors moved i put it back in place it was R3B19 that got moved did not attempt to giltch yet an did not write the ecc to the nand yet but wanted to make sure it was fine an greeted with the red dot......:facepalm::facepalm::frown:

Post pics of the area as well as anything that you installed



[Martin C]

You can't really tell from that shot. TBH looking at what I can see, you either need to improve the area and check other components, or get someone else to sort it for you. Right now it's fixable.



[KhaineGB]

R3B15 looks slightly wonky to me as well, but as Martin said... it's hard to tell from the pic.



[x360ccm]

post a better pic tbh.

then you get a better answer.



[MeAnRG]

Well if you look at where j2c3 there are two resistors there also an one looks damaged not there i think i am screwed here are better pics :frown::facepalm::facepalm:

The spots on this pic are the areas i am concerned with:

Heres a pic of another slim looks like i really f**ked up an not noticed tell the last minute.....



[MeAnRG]

You can't really tell from that shot. TBH looking at what I can see, you either need to improve the area and check other components, or get someone else to sort it for you. Right now it's fixable.

Posted new pics can you please or some body have a look:facepalm:



[x360ccm]

Well if you look at where j2c3 there are two resistors there also an one looks damaged not there i think i am screwed here are better pics :frown::facepalm::facepalm:

Link To Image

Link To Image

The spots on this pic are the areas i am concerned with:

Link To Image

Heres a pic of another slim looks like i really f**ked up an not noticed tell the last minute.....

Link To Image

if you dont mind me askin but how the hell you managed to mess them up in your 3rd photo.:rolleyes2:

it can be fixed but ffs leave it to a pro.



[MeAnRG]

if you dont mind me askin but how the hell you managed to mess them up in your 3rd photo.:rolleyes2:

it can be fixed but ffs leave it to a pro.

no mess up in the 3rd pic that was for comparison purposes lolz its the first two but how can i fix this trace an solider wire from one end to the trace even if a resistors supposed to be there...?



[mespo365]

Resistors need to be replaced at a min. Hard to tell if your trace is fine? I would suggest sending it to a pro. Where u from?



[MeAnRG]

Resistors need to be replaced at a min. Hard to tell if your trace is fine? I would suggest sending it to a pro. Where u from?

i live in the us maryland....?



[WalangAlam]

perhaps we should start using alternate points so to avoid these...



[MeAnRG]

I don't no what to do how can i replace the resistors an if not is there anybody in the us that can fix that's a pro on the fourms...???



[x360ccm]

no mess up in the 3rd pic that was for comparison purposes lolz its the first two but how can i fix this trace an solider wire from one end to the trace even if a resistors supposed to be there...?

so this aint your mess up..

anyone of the guys in the sticky will fix your messed up mobo.

http://www.team-xecuter.com/forums/forumdisplay.php?f=150



[KhaineGB]

Wow... looks like you definitely lost at least 3 resistors... possible trace damage...

And I could be wrong, but it looks like you used WAY too much flux on your motherboard.



[MeAnRG]

so this aint your mess up..

Link To Image

anyone of the guys in the sticky will fix your messed up mobo.

http://www.team-xecuter.com/forums/forumdisplay.php?f=150

Wow... looks like you definitely lost at least 3 resistors... possible trace damage...

And I could be wrong, but it looks like you used WAY too much flux on your motherboard.

LOL yea @dgenx that is a mess up there i was talking bout the pic with the QSB sorry @KhaineGB yea i think i did too that why they prob came off but i found an old USB stick with the same small resistors it appears to look like will they work...?? just a question



[marshamods]

I would not recommend it. If you are in the us let me know which resistors you need and I will post them to you if you pay for the postage



[x360ccm]

if you lifted them resistors then i stop.and send to a pro.

marshamods may fix it for you , ask him.

i sure he can..



[MeAnRG]

I would not recommend it. If you are in the us let me know which resistors you need and I will post them to you if you pay for the postage

i would say i need the three that are missing but they don't have any numbers on them they are so small the resistors an yea I'll pay the postage if you can fix it i'll even send it to you an pay the postage there an back.



[x360ccm]

they are small.and you cant expect to just pay postage and get it fixed,
