Cant use the nand-x

[tonyjandc]

blakey beat me to it lol . nine times out of ten its either cold or bad solder .

---------- Post added at 16:18 ---------- Previous post was at 16:17 ----------

double check your ground (yellow) this can the most troublesome.



[techxex]

Soldering photos



[BL4K3Y]

That soldering looks fine from what I can tell.

Try another USB port and follow this to help you install the drivers.



[techxex]

That soldering looks fine from what I can tell.

Try another USB port and follow this to help you install the drivers.

still get the same error



[Krafter]

I only see 6 wires. Shouldn't there be one on J2b1.6?



[BL4K3Y]

Well I have suggested everything I can think of right now.

Maybe try reading here.

I only see 6 wires. Shouldn't there be one on J2b1.6?

Look closely, you can see the black wire just tucked behind .



[Krafter]

OK, I think I see the missing green wire in the pics but it almost looks like the blue and green are reversed.

Look here

http://www.team-xecuter.com/forums/showthread.php?t=54355

---------- Post added at 18:52 ---------- Previous post was at 18:52 ----------

It was the green wire that I wasn't seeing.



[techxex]

I have 7 wires and blue and green wires are correct.



[TheRealKTFO]

it almost looks like the blue and green are reversed.

Look here

http://www.team-xecuter.com/forums/showthread.php?t=54355

The green and blue are correct according to the diagram in the link.



[Krafter]

I'm just color blind I guess.



[techxex]

OK, I think I see the missing green wire in the pics but it almost looks like the blue and green are reversed.

Look here

http://www.team-xecuter.com/forums/showthread.php?t=54355

---------- Post added at 18:52 ---------- Previous post was at 18:52 ----------

It was the green wire that I wasn't seeing.

I also forgot this photo



[TheRealKTFO]

Personally, I would re-solder the yellow and the red wires. The yellow one looks a "little" dodgy and the red wire just looks like it sitting on the edge of the pad...

Really can't see the brown wire connection, might want to look at that one also??

Just my .02



[techxex]

New soldering



[TilVl]

Tried to reset the nandx with the small button?

Sent from my SGH-T839 using Tapatalk



[techxex]

Tried to reset the nandx with the small button?

Sent from my SGH-T839 using Tapatalk

yes.

Also is still get this error

"NandPro v3.0a by Tiros

Looking for usb interface device
Can not continue"



[TheRealKTFO]

Nand-X might have gone south



[techxex]

Nand-X might have gone south

I dont get why.

Also my photos are wrong in my post above



[jeremy790]

My first nandx worked great for about 20 boxes or so then I went to do a slim and it started throwing errors during the dump. So thinking it was soldering I rechecked all the connections and the tested fine. So I tried to dump firmware again and got the same message you are getting. After posting a thread and talking to several people I decided to order a new nandx and it worked like a charm. Someone had mentioned if you power up the xbox with the nand x connected it could damage it. In my situation it showed in the device manager and would program the cr but would not dump a nand.



[techxex]

I still cant get this thing to work. Can anyone help me

Also heres the wright photos:



[BL4K3Y]

You need to swap the brown and orange wires around .
