CK3i to Nand-X Autobaud error

X

xxxenvy

Junior Member
Sep 4, 2011
20
0
Hi, i've searched all over the forums and google and could not find anything that could help me resolve the Autobaud issue from flashmagic. Im trying to update my Nand-X from v2 (bought a few months ago and never used until now). I followed Ubers guide down to the details. Heres what i've already done.

-Checked the connections of the CK3i to NAnd-X Cable
-Checked if the pins are in the right slots of the cable
-Tried different flashmagic versions
-Tried different COM ports
-Tried different USB slots (and different USB cables)
-Tried different WINDOWS (64 and 32, XP, vista, 7)
-Tried different machines (PC, Laptop)
-Tried Oscillator from 12 to 14.745
-Tried all different Baud Rates
-Double checked the ARMv3.HEX file location
-Uninstalled and reinstalled CK3i drivers
-Powered off and on the Power switch on CK3i
-Pushed the reset button on the NAND-X prior to clicking start on flashmagic.

Im not sure what else i can do to make this work. Im attached my setup just in case anyone wanted to assist.








Last edited:
X

xxxenvy

Junior Member
Sep 4, 2011
20
0
xbox360 hacker said:
Don't think think it makes a difference but you could try changing to normal as your using the ck3i in mode_b at the moment.

Edit: Baud rate should be 9600 and why is there no options in step 2 there should be 2 check boxes
Click to expand...
The boxes are not there because it was a different version of flashmagic when i took the screenshot. I can confirm that i checked the one box per the tutorial on the latest version of flashmagic, still failed.


nastybrother24 said:
it could just be your nand x as i can update 2 out of 3 of mine
Click to expand...
Kind of defeats the purpose of updating since the new one i get will be preflashed with v3.. i really hope theres a way around this, i really dont want to spend another 40 dollars buying another nand-x.

Forgot to mention that my Nand-x is not recognized when i plug it into my machine, no connections whatsoever, the red light comes on but no driver installations or prompts and none of that.
