Please redo the soldering. Cut the ends a bit shorter to have less bare wire showing, just enough to create a solid connection. Use flux and pretin the points you are soldering to.Here are some pics of install
The orange wire may not look well attached from these pictures, but I used a multimeter to confirm that it is connected to where it needs to be and not to where it not needs to be. Also, the blue wire is not touching the other pad, it just may look like that from this angle.
I was lucky and found a nice pointy tip which is the only reason i am able to make it this nice (to me). All that black stuff is just insulations that melted on the older tip and rubbed off. I used a multimeter to confirm good contact at that point. Notice you can barely see where the trace was scratched up to test for continuity. As for the B point, that resistor (the side closest to the target) is actually on the same trace. Thats why the alternate connection point starts on the other side of that resistor.I don't like your "A" and "B" points they look too messy and you are coming in on the A point over the resistor, you be should coming in on the left where there is no point and your exposed wire is to long, could be touching other points, keep them short. Also what watt iron are you using?, all your soldering looks a bit cold and use some alcohol to clean the flux off, you will get a better look at your connections
nice lol ur soldering what is they call bad lol u need to practice a lot more before u can rule out ur soldering as being the problem. if the green light is not flashing then ur wiring or coolrunner is the problemI was lucky and found a nice pointy tip which is the only reason i am able to make it this nice (to me). All that black stuff is just insulations that melted on the older tip and rubbed off. I used a multimeter to confirm good contact at that point. Notice you can barely see where the trace was scratched up to test for continuity. As for the B point, that resistor (the side closest to the target) is actually on the same trace. Thats why the alternate connection point starts on the other side of that resistor.
I will see what I can do...
