RGH Coolrunner question

[Naruto-007]

I try to install my coolrunner on my falcon but i fall. thei i solder it correctly to my zephyr xbox and i dump the nand correctly. but know went i soldered my coolrunner my xbox wont start WTF!!! i take of the coolrunner and its not starting up... that 2 xbox in a row and i dont have any money to buy one (im 17) what can i do

Last Pic goes the B cable (orange) I accidentally remove it



[Rock]

Take a picture of all ur soldering cause u may have points bridged



[WestCoastConsoles]

We need more info. Pics of areas that install was attempted. What's the color of the light on the power brick. Did you flash original NAND back after writing to it.



[mocalacace]

I had this same problem, make sure after you flash your NAND to unplug your xbox for 30 seconds. Sounds crazy, but it works



[loalge]

Check area around stby_clk for lifted pad or for missing or loose resistor.



[Naruto-007]

ill be posting pic in a sec. i dint flash the ecc i only dump the nand 4 time to compare it

---------- Post added at 00:09 ---------- Previous post was at 00:07 ----------

the light of the power brick is orange and the coolruner red and green



[loalge]

If the coolrunner is solid red and solid green then it didn't get programmed.



[Naruto-007]

i dint program it cause my nand-x is 2.0 im going to send it to xconsole so they can upgrade it



[loalge]

It looks like from pic that stby_clk point was damaged.



[Naruto-007]

can i fix that?



[loalge]

It can be fixed. whether a person struggling with it should attempt it is debateable. see http://www.team-xecuter.com/forums/showthread.php?t=74992 for instruction on fix or send to someone to fix.



[Naruto-007]

i think is that my 2 xbox got that part damage. going to try to fix it know and let you know what happen



[loalge]

Good luck to ya. I've fixed 2 of those myself and it's a bit of a bitch but just be patient and calm and you'll get it!

Just a suggestion if you're going to continue with the RGH, if you get it repaired and it is booting, hot glue it and solder your stby_clk to the alternate solder point. I did that and it worked like a charm.



[Naruto-007]

It can be fixed. whether a person struggling with it should attempt it is debateable. see http://www.team-xecuter.com/forums/showthread.php?t=74992 for instruction on fix or send to someone to fix.

Thank you so much sososososososos much it workink now OMG you save my live i own you so much now!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!



[loalge]

Holy crap!! :eek2: You're fast!
Lol.
Congrats! Glad to hear it. Now don't forget to protect your repair with hot glue and solder to alternate point.



[Naruto-007]

yeah i was so nervous that i take a slim cable cut it and solder it and wala now i have to go to my neighbor and ask the for hot glue



[Naruto-007]

now my two xbox are working thank you again XD



[loalge]

Hell Yeah!! Good job.
