RGH Coolrunner stays red, no green blinking

[whataretheyfeedingyou]

got a head scratcher.

installed a coolrunner in a slim and no green light is appearing. the fans go as if it is glitching but no green light or xell.

I've redone points, tried alternative and a different coolrunner.

pics posted, can anyone shed any light



[Martin C]

wrong post_out used.

d'oh!



[whataretheyfeedingyou]

wrong post_out used.

d'oh!

the orange one? thats the alternative point. the original didn't work either

---------- Post added at 14:21 ---------- Previous post was at 14:21 ----------

the orange one? thats the alternative point. the original didn't work either

my bad!!!! the yellow one!!! skool boy error



[Martin C]

that's stby_clk.

2nd image, yellow wire. you've soldered it to the wrong point. You need to be one along.



[whataretheyfeedingyou]

got another drama on another one if you could help martin.

got a bad nand on one. that will only boot xell. no dash.

I only have 2 nand dumps that already have the ECC wrote to them. I also wrote the wrong dash to it. its a really mess.

Is there any way of stripping the ECC off one of those nanddumps so its orginal again?



[Martin C]

If you have a full NAND dump with the ECC written to it, you can rescue the keyvault and config, then build a good NAND using a donor as a base.

Thanks for posting the pics though, proves why we ask for them



[whataretheyfeedingyou]

If you have a full NAND dump with the ECC written to it, you can rescue the keyvault and config, then build a good NAND using a donor as a base.

Thanks for posting the pics though, proves why we ask for them

nice, do i do that in multi builder yeah?



[Martin C]

Well no, it's a manual process.



[whataretheyfeedingyou]

Well no, it's a manual process.

bugger, will shove it back in the cupboard
