FIXED Corona V1 Crashing

[shawnunder7]

Hello all, i am having an issue with getting the DGX to work on a Corona V1. I dumped the nand and wrote the DGX.ecc and wired the DGX itself. When i boot the console, it glitches about 6-7 times and then seems to crash (fans make the noise it makes while glitching but continuously). I also tried Martin's Corona2.ecc and the console will either boot and after 6 glitches it will red dot or it will crash. I'm kinda confused now as ive been trying wire placements and alt points with no luck. Here are my logs and pictures as i read enough threads to what must be supplied.

Saturday, January 19, 2013 12:27:08 PM

J-Runner v0.2 Beta (284) Started


Consider fellow users, Save bandwidth, please have only minimum number of dashes selected.
Checking Files
Finished Checking Files
Version: 01
Flash Config: 0x00043000
CB Version: 13181
Corona
Reading Nand to C:\Users\Shawn\Desktop\J-Runner v02 (278) Core Pack\output\nanddump1.bin
Reading Nand
Done!
in 5:12 min:sec

Reading Nand to C:\Users\Shawn\Desktop\J-Runner v02 (278) Core Pack\output\nanddump2.bin
Initializing nanddump1.bin..
Nand Initialization Finished
Reading Nand
Done!
in 5:12 min:sec

Comparing...
Nands are the same
Version: 01
Flash Config: 0x00043000
Writing Nand
CORONA_16MB_DGX.ecc
Done!
in 0:28 min:sec



[modguru]

try with longer or shorter post out cable ... the most times this is the reason for crashing and check the switch 8 in the dgx to be on and the rest off



[Martin C]

Why are you using such a long POST_OUT? Where do we advise this?



[shawnunder7]

Why are you using such a long POST_OUT? Where do we advise this?

You are absolutely correct! I saw that some other people had very good results so i decided to also try that, but it didn't work. I took some 28awg wire and cut it to about 11CM and it booted in about 8 glitches. Got the key via COMM and time to CR3 Lite it. Never will i not exactly follow the guide again :biggrin:



[Martin C]

No worries - glad you got it sorted
