Corona V2 4GB QSB Nand Reader failed create ecc and power wont On

S

syaugi

Full Member
Jan 5, 2015
57
6
Australia
TX Product(s) used: JR Programer V2 and CR4 Xl
Console Type: Corona V2 4GB
NAND size: 4GB
Dashboard version: e.g 2.0.17150
CB version:
Screenshot of NAND details from J-Runner:
(attach an image to your post)
J-Runner log:
updflash.bin log (if applicable):
Image of Coolrunner:
Images of close-up soldering to motherboard:
(attach images to your post)

Description of problem: always failed create ecc and power wont turn on, and first time was inserted nand reader usb to computer, asked me to format, and i have formatted :(

Was the console working before you started: Yes

Do you get a green debug light appear on the RGH chip every 4-5 seconds: no

How long is the light on for each time: nothing

(be aware that if you're trying to work on a faulty console, this is not a T-X product issue!!).

===================================================
Tuesday, March 24, 2015 8:06:41 AM

J-Runner v0.3 Beta (7) Started


WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button


Checking Files
Finished Checking Files
Initializing nanddump1-2.bin..
Header is wrong..
Comparing...
Can't check for bad blocks. No Spare data. Possibly Corona 4GB
Can't check for bad blocks. No Spare data. Possibly Corona 4GB
Nands are the same
Glitch2 Selected
CR4 Selected
Header is wrong..
Failed to create ecc image
Corona 4GB Manually Selected
Header is wrong..
Failed to create ecc image
Header is wrong..
Failed to create ecc image
Click to expand...

















Last edited:
Brickmii82

Brickmii82

Junior Member
Mar 19, 2015
20
0
Arizona, USA
If you formatted the drive when you first plugged in the reader, you may need to send it out. That basically means you erased all the data on your xbox. Someone will have to create a retail image from scratch.

BrockThunderjam

BrockThunderjam

VIP Member
Jun 25, 2013
1,503
88
Brickmii82 said:
If you formatted the drive when you first plugged in the reader, you may need to send it out. That basically means you erased all the data on your xbox. Someone will have to create a retail image from scratch.
Click to expand...
You can't create a retail image from scratch like that, only freeboot if the nand is formatted like he said. OP, do you have a copy of the nand dump you originally read before writing the ecc? if so, try writing it back, disconnect 5V from the CR4 and try to boot.

If not, you need to write the CR4 corona ecc found in the JRunner common folders, boot to xell to grab your keys, build yourself a freeboot image using donor KV info, and this console will have to stay RGH (no retail available).

Last edited:
  • Like
Reactions: Brickmii82
S

syaugi

Full Member
Jan 5, 2015
57
6
Australia
BrockThunderjam said:
You can't create a retail image from scratch like that, only freeboot if the nand is formatted like he said. OP, do you have a copy of the nand dump you originally read before writing the ecc? if so, try writing it back, disconnect 5V from the CR4 and try to boot.

If not, you need to write the CR4 corona ecc found in the JRunner common folders, boot to xell to grab your keys, build yourself a freeboot image using donor KV info, and this console will have to stay RGH (no retail available).
Click to expand...
Yes still have this nand :
Header is wrong..
Comparing...
Can't check for bad blocks. No Spare data. Possibly Corona 4GB
Can't check for bad blocks. No Spare data. Possibly Corona 4GB
Nands are the same

i have disconnected 5V from CR4 XL and try to write nand and Access to the path is denied.
and still wont turn ON the xbox

Wednesday, March 25, 2015 5:50:39 PM

J-Runner v0.3 Beta (7) Started


WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button


Checking Files
Finished Checking Files
Initializing nanddump1-2.bin..
Header is wrong..
Comparing...
Can't check for bad blocks. No Spare data. Possibly Corona 4GB
Can't check for bad blocks. No Spare data. Possibly Corona 4GB
Nands are the same
Corona 4GB Manually Selected
Writing to I:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack\output\nanddump1-2.bin
Access to the path is denied.
Click to expand...
denied :(

Last edited:
alexander_1333

alexander_1333

VIP Member
Jan 10, 2012
980
0
Slovakia
Upload what you have from this console(nanddump.1,2,3....) and send me the link.

Edit: if you are 100% sure you formated the nand, do what BrockThunderjam said.The drive will not play games anymore, anyway you can make it play with a LTU/LTU2/16d4s PCB.And no retail nand for this console.

Last edited:
S

stucknvegas

VIP Member
Oct 25, 2012
656
0
Cypress CA. USA
I think he scrubbed the original nand by his description ..Real Mod Scene has a good tutorial on Building a RGH nand when you lost everything
Your console will only be RGH never retail again if you erased that original nand... I have done it before and I got the same symptom..Flat line

S

syaugi

Full Member
Jan 5, 2015
57
6
Australia
alexander_1333 said:
Upload what you have from this console(nanddump.1,2,3....) and send me the link.

Edit: if you are 100% sure you formated the nand, do what BrockThunderjam said.The drive will not play games anymore, anyway you can make it play with a LTU/LTU2/16d4s PCB.And no retail nand for this console.
Click to expand...
please have a look my Nand https://drive.google.com/file/d/0Bymy86SVHDribk5Da1puSE9lLVU/view?usp=sharing


stucknvegas said:
I think he scrubbed the original nand by his description ..Real Mod Scene has a good tutorial on Building a RGH nand when you lost everything
Your console will only be RGH never retail again if you erased that original nand... I have done it before and I got the same symptom..Flat line
Click to expand...
can you please give me tutorial how to real mod scene without original Nand ?

i have tried to re-write Nand but always denied

Joo C

Joo C

VIP Member
Dec 2, 2011
748
48
South Africa
Start by removing those nand wires - in fact you can remove the CR4 as your goal now is to first restore power to the console by writing a valid nand. Those nand wires are not the same as the qsb as they have a completely different layout on the model you're attempting to mod.

S

stucknvegas

VIP Member
Oct 25, 2012
656
0
Cypress CA. USA
HE Has already ben told that wires are not for this model If you have not removed the nand wires do so now !!!
NOW AT THIS POINT HE IS TRYING TO RECOVER FROM A BAD FLASH

S

syaugi

Full Member
Jan 5, 2015
57
6
Australia
stucknvegas said:
HE Has already ben told that wires are not for this model If you have not removed the nand wires do so now !!!
NOW AT THIS POINT HE IS TRYING TO RECOVER FROM A BAD FLASH
Click to expand...
i have followed this step http://www.realmodscene.com/index.p...to-build-a-new-nand-when-you-lost-everything/
but i could write ecc :(, this is my installed cable cr4 xl, any something wrong ?



Code:
Glitch2 Selected
CR4 Selected
CpuKey is Correct
CpuKey is Correct
Load Files Initiliazation Finished
17150
Started Creation of the 17150 xebuild image
---------------------------------------------------------------
     xeBuild v1.14.693
---------------------------------------------------------------
base path changed to C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild
---- { Image Build Mode } ----
building glitch2 image


******* WARNING: could not verify pre-decrypted keyvault, please be sure your provided a valid kv.bin!
---------------------------------------------------------------
C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.17150.0
Console   : Corona
NAND size : 48MiB MMC (system only)
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 003393323109
ConsoleId : 320663201070
MoboSerial: 9501126103842319
Mfg Date  : 07/30/2012
CPU Key   : F37C0CD50B928F4E67614ACD548A4E49
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : D24670CA345A562A1816D522B92C5FC6
CF LDV    : 2
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Saved to C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109
Image is Ready
Initializing updflash.bin..
CpuKey is Correct
Added Key to Database
Extracting..
Saving SMC_en.bin
Saving SMC_dec.bin
Saving KV_en.bin
Saving KV_dec.bin
Saving smc_config.bin
Working...
Saving fcrt_en.bin
Saving fcrt_dec.bin
Saving C-R.bin
Saving key.bin
Done
Save location C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\output\Extracts-003393323109
Corona 4GB
Nand Initialization Finished
Must be a removable type
Must be a removable type
Must be a removable type

===================================================
Thursday, April 02, 2015 8:17:50 AM

J-Runner v0.3 Beta (7) Started



Checking Files
Finished Checking Files
Initializing updflash.bin..
Corona 4GB
Glitch2 Selected
Nand Initialization Finished
Writing to H:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin
Access to the path is denied.
Writing to H:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin
The process cannot access the file 'C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin' because it is being used by another process.
Writing to H:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin
The process cannot access the file 'C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin' because it is being used by another process.
Writing to H:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin
Done!
in 0:07:326 min:sec:ms
CR4 Selected
ECC created
ECC created
ECC created

===================================================
Thursday, April 02, 2015 8:32:36 AM

J-Runner v0.3 Beta (7) Started


WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button


Checking Files
Finished Checking Files
Initializing updflash.bin..
Corona 4GB
Glitch2 Selected
Nand Initialization Finished
CR4 Selected
Writing to H:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin
Done!
in 0:07:74 min:sec:ms
ECC created
Initializing updflash.bin..
Corona 4GB
Nand Initialization Finished
ECC created

===================================================
Thursday, April 02, 2015 8:39:15 AM

J-Runner v0.3 Beta (7) Started


WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button


Checking Files
Finished Checking Files
Initializing updflash.bin..
Corona 4GB
Glitch2 Selected
Nand Initialization Finished
ECC created
Connection TimeOut
ECC created
Initializing updflash.bin..
Corona 4GB
Nand Initialization Finished
CR4 Selected
ECC created
ECC created

===================================================
Thursday, April 02, 2015 8:47:13 AM

J-Runner v0.3 Beta (7) Started


WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button


Checking Files
Finished Checking Files
Initializing updflash.bin..
Corona 4GB
Glitch2 Selected
Nand Initialization Finished
Initializing updflash.bin..
Corona 4GB
Nand Initialization Finished
CR4 Selected
Writing to H:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\003393323109\updflash.bin
Done!
in 0:07:102 min:sec:ms
ECC created

S

stucknvegas

VIP Member
Oct 25, 2012
656
0
Cypress CA. USA
Please remove the Nand wires de-solder them Everyone keeps asking just remove them
Then are you getting the format prompt in Jrunner Looks like you are
Then looks like you wrote the dummy retail nand but not showing you wrote the ECC
Remember when testing the console to power on set the 4gig card reader QSB to xbox
