Corona V2 4GB QSB Nand Reader failed create ecc and power wont On
- Thread starter syaugi
- Start date
i have removed Nand wires, but from cr4 xl only came out red light and power ON ..it was not going to xell boot
GeekHeat
VIP Member
have u created and written ecc. av u tried different dips, post jumper settings. I wud remove that cap. it not needed at this point.
ecc created and when i clicked write ecc its like nothing happens
(i have removed the cap and still same thing )
Last edited:
i have removed Nand wires, but from cr4 xl only ?
What does this mean ..it does not make sense... Did you remove the 7 wire harness for JRprogrammer
post a picture of your current work
The xbox will red dot at this point it is normal until you write the ECC to the console
Are you doing this Restart your PC> sound card reader disconected
Xbox power supply pluged in
4 Gig QSB adapter switch set to write> then connect to PC
Format prompt > No>..Load your created Dummy retail Image in load source
Select glitch-2 >CR4 create ECC > Write ECC> select> Removable> Then select Write
What does this mean ..it does not make sense... Did you remove the 7 wire harness for JRprogrammer
post a picture of your current work
The xbox will red dot at this point it is normal until you write the ECC to the console
Are you doing this Restart your PC> sound card reader disconected
Xbox power supply pluged in
4 Gig QSB adapter switch set to write> then connect to PC
Format prompt > No>..Load your created Dummy retail Image in load source
Select glitch-2 >CR4 create ECC > Write ECC> select> Removable> Then select Write
Code:
===================================================
Friday, April 03, 2015 1:32:07 AM
J-Runner v0.3 Beta (7) Started
WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button
Checking Files
Finished Checking Files
Initializing updflash.bin..
Corona 4GB
Glitch2 Selected
Nand Initialization Finished
CR4 Selected
ECC created
Writing to H:\ from C:\Users\FaathimahAminah\Desktop\J-Runner v3 (5) Core Pack\J-Runner v3 (5) Core Pack - Copy\xeBuild\output\image_00000000.ecc
Done!
in 0:00:361 min:sec:ms
and tried dips :
8.1 with 0ohms, 8.1 with 10ohms, 8.1 with 100ohms
8.2 with 0ohms, 8.2 with 10ohms, 8.2 with 100ohms
8.3 with 0ohms, 8.3 with 10ohms, 8.3 with 100ohms
still wont to get xell
Last edited:
only red light,
i just wondering, my installation cable points on the cr4 is correct?
Last edited:
nofeloniesyet
VIP Member
The center Green light of the ROL sinc board is Green correct... the console is attempting to start when powering on correct if yes
Remove yellow post out wire from Cr-4 > Test ohms continuity yellow wire to ground
Remove yellow post out wire from Cr-4 > Test ohms continuity yellow wire to ground
Joo C
VIP Member
My view is that you should write back your original nand, disconnect power from the CR4, if the console boots it confirms you're good to start again
He erased the Original nand so that's not happening
If you do not have a Meter let us know, and one of us will show you how to verify post out removed
If you do not have a Meter let us know, and one of us will show you how to verify post out removed
Last edited:
Joo C
VIP Member
My bad stucknvegas, missed your confirmation that the nand is fooked, no choice but to RGH with no possibility of retail...
yes, there is full post under xcgpu
The center Green light of the ROL sinc board is Green correct --> YES
the console is attempting to start when powering on correct if yes --> YES
Remove yellow post out wire from Cr-4 --> i have removed it now
Test ohms continuity yellow wire to ground --> not sure with this step ( i removed yellow post out wire from Cr-4 and then connect to ground ) -->still same thing
and also removed yellow post out wire from cr4 -->still same thing too
only red light came out
john mathews
VIP Member
some v2 models are missing post out just pop xclamp and look/ did u switch the 4g qsb to 360 and remove the wires when glitching
Last edited:
Hooking the post out yellow to ground--and powering on is a big no-no ..I hope you did not do damage
Do you have a multimeter now we really need to test the ohms post out short to ground
For now stick to settings post out 0 or 10-) have you tried dip 8-4 or 8-5
You can also write the dummy retail upflash bin back to the console then remove 5v from the chip
Start the console it should red ring after 20-25 seconds with secondary error 0022
Then if it does then write the ECC again and test for CR-4 green light
Do you have a multimeter now we really need to test the ohms post out short to ground
For now stick to settings post out 0 or 10-) have you tried dip 8-4 or 8-5
You can also write the dummy retail upflash bin back to the console then remove 5v from the chip
Start the console it should red ring after 20-25 seconds with secondary error 0022
Then if it does then write the ECC again and test for CR-4 green light
