Corona V2 4GB QSB Nand Reader failed create ecc and power wont On

[syaugi]

by any chance u have another chip to try

i don't have at the moment, how do i can check if chip is faulty ?



[john mathews]

i don't have at the moment, how do i can check if chip is faulty ?

lucky enough for me I had extras to try n they all worked except the 1 I tried so in short I don't think so on are end at least may havebto return like im doing



[stucknvegas]

With just your created dummy retail upflash bin written to the console no ECC should red dot after 30- seconds
Let me do a couple test for the Blue Cpu-rst wire



[syaugi]

lucky enough for me I had extras to try n they all worked except the 1 I tried so in short I don't think so on are end at least may have to return like im doing

I'm not sure they will accept to return or not, i lost the invoice for it

With just your created dummy retail upflash bin written to the console no ECC should red dot after 30- seconds
Let me do a couple test for the Blue Cpu-rst wire

unfortunately i didn't get red dot from the console only green light, thanks stucknvegas for helping me



[stucknvegas]

TX sellers always honer returns ..Never had any warranty return problems They will except returning your chip
We will do a couple more test just give me a minute



[stucknvegas]

With your meter set to Ohms and the blue and green wire disconnected from the CR-4
Black meter lead to ground
Blue wire should yield 53.0
Green wire 2.000
With the Meter red wire to ground and Black lead to pad D on CR-4 (yield should be 52.0



[syaugi]

TX sellers always honer returns ..Never had any warranty return problems They will except returning your chip
We will do a couple more test just give me a minute

ill try to contact them ..

With your meter set to Ohms and the blue and green wire disconnected from the CR-4
Black meter lead to ground
Blue wire should yield 53.0
Green wire 2.000
With the Meter red wire to ground and Black lead to pad D on CR-4 (yield should be 52.0

i will try next 4-5 hours ( at work at the moment )
thank you very much stucknvegas



[stucknvegas]

I am not convinced there is any problem with your CR-4 at this point
Your console should red dot with your created upflash bin
No red dot means you still have ECC written to the Machine or your console has a problem
Corona 4-G can get nand corruption ..It is very common..
Watch the writing status bar in Jrunner wile performing the write of the upflash
One of the symptoms is you can read the nand but not write to it

PM your Email address and I will send you one of my Nands to try



[syaugi]

I am not convinced there is any problem with your CR-4 at this point
Your console should red dot with your created upflash bin
No red dot means you still have ECC written to the Machine or your console has a problem
Corona 4-G can get nand corruption ..It is very common..
Watch the writing status bar in Jrunner wile performing the write of the upflash
One of the symptoms is you can read the nand but not write to it

PM your Email address and I will send you one of my Nands to try

pm sent.
yeah i dont think so my cr4 problem.
i'll post the log later



[Krafter]

Okay. I did some testing on a good CR4 set to Slim. These are the results.


-------- Wires installed --------

• C = 0 TO 1.1
• M = 1.1 TO 0
• D = 1.9
• G = 1.9
• E = 1.3
• K = 0
• A = 1 TO 0
• B = 1.6
• CR_EN = 3.3

-------- Wires NOT installed --------

• C = 1.1
• M = 1.8
• D = 1.8
• G = 1.8
• E = 1.2
• K = 0
• A = 0
• B = 1.2
• CR_EN = 3.3

All these voltages are approximates and not exact measurements.



[stucknvegas]

I will save your results thanks Krafter



[Krafter]

It's probably safe to say that if points like M and D read 0V then it's not programmed. Those points I believe are output pins and should have voltage on them until it's time to send the Reset command.



[syaugi]

I am not convinced there is any problem with your CR-4 at this point
Your console should red dot with your created upflash bin
No red dot means you still have ECC written to the Machine or your console has a problem
Corona 4-G can get nand corruption ..It is very common..
Watch the writing status bar in Jrunner wile performing the write of the upflash
One of the symptoms is you can read the nand but not write to it

PM your Email address and I will send you one of my Nands to try

just tried and came out red dot


this is my result :
-------- Wires installed --------

C = 0
M = 1.91
D = 1.9
G = 1.9
E = unstable and dificult to get results ( have changed the cable and still unstable)
K = 3.35
A = 0
B = 0
CR_EN = 3.29



[syaugi]

the cr4 xl still won't glitches to get xell, its weird



[john mathews]

the cr4 xl still won't glitches to get xell, its weird

so the light not blinking green



[Krafter]

just tried and came out red dot


this is my result :
-------- Wires installed --------

C = 0
M = 1.91
D = 1.9
G = 1.9
E = unstable and dificult to get results ( have changed the cable and still unstable)
K = 3.35
A = 0
B = 0
CR_EN = 3.29

Disconnect all the wires from the chip expect 5V and GND and take measurements and compare to my readings. Since your getting 3.3 on the CR_EN and voltage on D and M then I'd say the chip is programmed.



[syaugi]

so the light not blinking green

no, tried have played around with dips and still didn't get blinking green

Disconnect all the wires from the chip expect 5V and GND and take measurements and compare to my readings. Since your getting 3.3 on the CR_EN and voltage on D and M then I'd say the chip is programmed.

this is new result :
-------- Wires installed --------

C = 0
M = 1.91
D = 1.9
G = 1.9
E = 0
K = 0
A = 0
B = 0
CR_EN = 3.29
