Corona V3 Bad Blocks

[yoohoomat]

I never write a nand unless I have good dumps with no errors but with this Corona V3 (first attempt at a Corona) but I get errors on 2 blocks on all my dumps just wanting to make sure this is ok before moving on to writing the DGX ecc. I will post my Jrunner log and will take me another minute to post pictures since I have to post those from my phone any help would be greatly appriciated. I am going to using a Demon so really don't matter I guess that I can't get a clean dump from the QSB but would like to make sure everything works properly. Also I know my QSB has a crystal it was one I had already ordered and I will be using the CRv3 Lite so I know there is no need for the crystal on the QSB. Thank you for the help below are pics and J runner log the log is long because I tried dumping twice on 3 dumps. One shows alot of errors so i checked for cold solder joints and tried again.

Sunday, January 27, 2013 12:00:19 AM
J-Runner v0.2 Beta (285) Started

Checking Files
Finished Checking Files
You have reached your dash download limit
You have reached your dash download limit
Version: 03
Flash Config: 0x00043000
CB Version: 13181
Corona
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump1.bin
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:26 min:sec
Initializing nanddump1.bin..
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump2.bin
Nand Initialization Finished
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:40 min:sec
Comparing...
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump3.bin
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Reading Nand
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Nands are the same
Error: 250 reading block 7C
Error: 250 reading block 7D
Error: 000 reading block 2E2
Error: 000 reading block 2E3
Error: 000 reading block 2E4
Error: 000 reading block 2E5
Error: 000 reading block 2E6
Error: 000 reading block 2E7
Error: 000 reading block 2E8
Error: 000 reading block 2E9
Error: 000 reading block 2EA
Error: 000 reading block 2EB
Error: 000 reading block 2EC
Error: 000 reading block 2ED
Error: 000 reading block 2EE
Error: 000 reading block 2EF
Error: 000 reading block 2F0
Error: 000 reading block 2F1
Error: 000 reading block 2F2
Error: 000 reading block 2F3
Error: 000 reading block 2F4
Error: 000 reading block 2F5
Done!
in 1:49 min:sec
Comparing...
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID @ 0x02E1 [Offset: 0xBE0200]
Bad Block ID @ 0x02E2 [Offset: 0xBE4400]
Bad Block ID @ 0x02E3 [Offset: 0xBE8600]
Bad Block ID @ 0x02E4 [Offset: 0xBEC800]
Bad Block ID @ 0x02E5 [Offset: 0xBF0A00]
Bad Block ID @ 0x02E6 [Offset: 0xBF4C00]
Bad Block ID @ 0x02E7 [Offset: 0xBF8E00]
Bad Block ID @ 0x02E8 [Offset: 0xBFD000]
Bad Block ID @ 0x02E9 [Offset: 0xC01200]
Bad Block ID @ 0x02EA [Offset: 0xC05400]
Bad Block ID @ 0x02EB [Offset: 0xC09600]
Bad Block ID @ 0x02EC [Offset: 0xC0D800]
Bad Block ID @ 0x02ED [Offset: 0xC11A00]
Bad Block ID @ 0x02EE [Offset: 0xC15C00]
Bad Block ID @ 0x02EF [Offset: 0xC19E00]
Bad Block ID @ 0x02F0 [Offset: 0xC1E000]
Bad Block ID @ 0x02F1 [Offset: 0xC22200]
Bad Block ID @ 0x02F2 [Offset: 0xC26400]
Bad Block ID @ 0x02F3 [Offset: 0xC2A600]
Bad Block ID @ 0x02F4 [Offset: 0xC2E800]
Bad Block ID @ 0x02F5 [Offset: 0xC32A00]
Bad Block ID @ 0x02F6 [Offset: 0xC36C00]
Bad Block ID @ 0x02F7 [Offset: 0xC3AE00]
Bad Block ID @ 0x02F8 [Offset: 0xC3F000]
Bad Block ID @ 0x02F9 [Offset: 0xC43200]
Bad Block ID @ 0x02FA [Offset: 0xC47400]
Bad Block ID @ 0x02FB [Offset: 0xC4B600]
Bad Block ID @ 0x02FC [Offset: 0xC4F800]
Bad Block ID @ 0x02FD [Offset: 0xC53A00]
Bad Block ID @ 0x02FE [Offset: 0xC57C00]
Too Many Bad Blocks
0x02E1
0x02E2
0x02E3
0x02E4
0x02E5
0x02E6
0x02E7
0x02E8
0x02E9
0x02EA
0x02EB
0x02EC
0x02ED
0x02EE
0x02EF
0x02F0
0x02F1
0x02F2
0x02F3
0x02F4
0x02F5
0x02F6
0x02F7
0x02F8
0x02F9
0x02FA
0x02FB
0x02FC
0x02FD
0x02FE
0x02FF
0x0300
0x0301
0x0302
0x0303
0x0304
0x0305
0x0306
0x0307
0x0308
0x0309
0x030A
0x030B
0x030C
0x030D
0x030E
0x030F
0x0310
0x0311
0x0312
0x0313
0x0314
0x0315
0x0316
0x0317
0x0318
0x0319
0x031A
0x031B
0x031C
0x031D
0x031E
0x031F
0x0320
0x0321
0x0322
0x0323
0x0324
0x0325
0x0326
0x0327
0x0328
0x0329
0x032A
0x032B
0x032C
0x032D
0x032E
0x032F
0x0330
0x0331
0x0332
0x0333
0x0334
0x0335
0x0336
0x0337
0x0338
0x0339
0x033A
0x033B
0x033C
0x033D
0x033E
0x033F
0x0340
0x0341
0x0342
0x0343
0x0344
0x0345
0x0346
0x0347
0x0348
0x0349
0x034A
0x034B
0x034C
0x034D
0x034E
0x034F
0x0350
0x0351
0x0352
0x0353
0x0354
0x0355
0x0356
0x0357
0x0358
0x0359
0x035A
0x035B
0x035C
0x035D
0x035E
0x035F
0x0360
0x0361
0x0362
0x0363
0x0364
0x0365
0x0366
0x0367
0x0368
0x0369
0x036A
0x036B
0x036C
0x036D
0x036E
0x036F
0x0370
0x0371
0x0372
0x0373
0x0374
0x0375
0x0376
0x0377
0x0378
0x0379
0x037A
0x037B
0x037C
0x037D
0x037E
0x037F
0x0380
0x0381
0x0382
0x0383
0x0384
0x0385
0x0386
0x0387
0x0388
0x0389
0x038A
0x038B
0x038C
0x038D
0x038E
0x038F
0x0390
0x0391
0x0392
0x0393
0x0394
0x0395
0x0396
0x0397
0x0398
0x0399
0x039A
0x039B
0x039C
0x039D
0x039E
0x039F
0x03A0
0x03A1
0x03A2
0x03A3
0x03A4
0x03A5
0x03A6
0x03A7
0x03A8
0x03A9
0x03AA
0x03AB
0x03AC
0x03AD
0x03AE
0x03AF
0x03B0
0x03B1
0x03B2
0x03B3
0x03B4
0x03B5
0x03B6
0x03B7
0x03B8
0x03B9
0x03BA
0x03BB
0x03BC
0x03BD
0x03BE
0x03BF
0x03C0
0x03C1
0x03C2
0x03C3
0x03C4
0x03C5
0x03C6
0x03C7
0x03C8
0x03C9
0x03CA
0x03CB
0x03CC
0x03CD
0x03CE
0x03CF
0x03D0
0x03D1
0x03D2
0x03D3
0x03D4
0x03D5
0x03D6
0x03D7
0x03D8
0x03D9
0x03DA
0x03DB
0x03DC
0x03DD
0x03DE
0x03DF
0x03E0
0x03E1
0x03E2
0x03E3
0x03E4
0x03E5
0x03E6
0x03E7
0x03E8
0x03E9
0x03EA
0x03EB
0x03EC
0x03ED
0x03EE
0x03EF
0x03F0
0x03F1
0x03F2
0x03F3
0x03F4
0x03F5
0x03F6
0x03F7
0x03F8
0x03F9
0x03FA
0x03FB
0x03FC
0x03FD
0x03FE
0x03FF
===================================================
Sunday, January 27, 2013 12:23:01 AM
J-Runner v0.2 Beta (285) Started

WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button
Connection Error
Checking Files
Connection Error
Version: 03
Flash Config: 0x00043000
CB Version: 13181
Corona
Version: 03
Flash Config: 0x00043000
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump1.bin
CB Version: 13181
Corona
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:11 min:sec
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump1.bin
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:10 min:sec
Initializing nanddump1.bin..
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump2.bin
Nand Initialization Finished
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:10 min:sec
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump3.bin
Comparing...
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Reading Nand
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Nands are the same
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:15 min:sec
Comparing...
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump2.bin
Initializing nanddump1.bin..
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Nand Initialization Finished
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Nands are the same



[Martin C]

Does your console still work? Have you written anything to it yet?



[yoohoomat]

No writing to it with bad blocks that would be stupid to do and yes it works nothing has been done besides reading the nand and qsb install. The 2nd set of dumps I did had remaps of bad blocks but I never rewrite a nand unless I have dumps with no errors and nands the same.



[Martin C]

Well that's not strictly true - understanding bad blocks is key.

I'm more concerned about all the other errors in there.

If the console still works ok, delete ALL existing nand dumps you've made (there's no reason to keep them at the moment) restart J-Runner and dump twice again. Post the resulting log from J-Runner.



[yoohoomat]

Alright I will delete and re read my nand and post the results



[Martin C]

As I can now see your soldering, the problem may be to do with the fact your QSBs aren't soldered properly.

Add flux and retouch with an iron - you shouldn't see any of the copper collar on each point.



[yoohoomat]

Alright I will add some more flux and solder clean up post new pic and j runner



[yoohoomat]

Cleaned the points put new flux added solder and made sure no copper points are showing then cleaned up ran J Runner did not get as many errors as before but still the same errors that were remapped. Here is the log

===================================================
Sunday, January 27, 2013 1:35:19 AM
J-Runner v0.2 Beta (285) Started

Checking Files
Finished Checking Files
You have reached your dash download limit
You have reached your dash download limit
Version: 03
Flash Config: 0x00043000
CB Version: 13181
Corona
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump1.bin
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:10 min:sec
Initializing nanddump1.bin..
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump2.bin
Nand Initialization Finished
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:10 min:sec
Comparing...
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump3.bin
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Reading Nand
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Nands are the same
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:14 min:sec
Comparing...
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Nands are the same



[Martin C]

You're not helping yourself at all.

Start again but this time actually do as I suggested.

Delete ALL existing dumps.

Restart J-Runner

Dump twice

Post the log



[yoohoomat]

That was with the nands deleted out of j runner and starting over after I resoldered refluxed cleaned deleted the original nand dumps from output folder and did fresh read



[Martin C]

So im seeing nanddump3.bin why?



[yoohoomat]

Cause I did not do 2 dumps I did 3 but all 3 came out exact same exact 2 bad.blocks



[Martin C]

So I ask you to dump twice and you do it three times.

Is there a problem with you doing as I advised or do you just like spewing log data out to a post? I'm trying to make sense of you're output and your inability to follow a simple task will most likely be your downfall.

So, let's start again.



[yoohoomat]

Sunday, January 27, 2013 3:13:43 AM
J-Runner v0.2 Beta (285) Started

WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button

Checking Files
Finished Checking Files
You have reached your dash download limit
You have reached your dash download limit
Version: 1E
Wrong Version.
Version: 03
Flash Config: 0x00043000
CB Version: 13181
Corona
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump1.bin
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:09 min:sec
Initializing nanddump1.bin..
Reading Nand to D:\Users\Mathew\Desktop\J-Runner v02 Beta (284) Core Pack\J-Runner v02 Beta (284) Core Pack\output\nanddump2.bin
Nand Initialization Finished
Reading Nand
Error: 250 reading block 7C
Error: 250 reading block 7D
Done!
in 2:09 min:sec
Comparing...
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]
Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]
Bad Blocks Remapped
Nands are the same



[Martin C]

Thanks - it was me being more pedantic than anything else, but it's easier to explain what's happening when I expect to see what I see:

Nands are the same

First off, NAND dumps match which is a good thing.

Bad Block ID @ 0x007C [Offset: 0x1FF800]
Bad Block ID @ 0x007D [Offset: 0x203A00]

Confirming your NAND has two bad blocks.

Bad Block ID 007C Found @ 0x03FF [Offset: 0x107BE00]
Bad Block ID 007D Found @ 0x03FE [Offset: 0x1077C00]

J-Runner has found the content of these blocks was already remapped by the Console (as they should be for correct NAND operation).

Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 007C [Offset: 0x1FF800]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 007D [Offset: 0x203A00]

J-Runner remaps them back for you to continue using the NAND image without an issue.

So you're fine to carry on with these dumps. The bad block is nowhere near XeLL so your ECC creation and write shouldn't be affected. When it's time to build the new image, J-Runner / Xebuild will remap these two blocks for you ready for writing.



[yoohoomat]

Thank you martin c that's what I thought to and was 99.9% sure but better to ask and get someone else's brain to confirm. I figured since it was not in my first 50 blocks it was OK seeing how it remapped them and cell only uses those first 50 blocks thanks for confirming.



[Martin C]

As I said, the remapping is a temporary thing to ensure your NANDs are valid for J-Runner operations. It's not 'fixing' anything at this stage. A bad block is a bad block.



[yoohoomat]

I don't plan on writing anything to the original nand but use the demon to run everything and this weekend when I have a chance install the demon and get a dump from it also see if I still get bad blocks but anyways use it to run my xell keep my original band on the Xbox untouched.



[Martin C]

For demon operation, ensure you choose 'noremap' in xebuild advanced options then write to the DemoN with Advanced/Write Fusion. Erase the DemoN NAND first though.



[yoohoomat]

Alright I will I am sure you or someone has written a tutorial on here I will locate if its out there (which I am sure there is) thanks for all your help martin will post again if I have anymore questions or concerns to anything I can not locate on the site.
