CR4 ROL instructions?

[Nelskeet517]

cant find them anywhere.... a link would be appreciated



[chase]

have a look HERE .. basically go from the CR4 ROL pad to your RF board led

[video=youtube;CxXdinyp6Po]https://www.youtube.com/watch?v=CxXdinyp6Po[/video]



[Nelskeet517]

I don't have that point please help



[Nelskeet517]

can I just plug this in and it work?



[gavin_darkglide]

If you mean solder a wire from the rol point to an led on the rol board, then yes, you can just plug it in. If that isnt what you meant, then I dont know what to tell you.



[chase]

make sure you solder to the positive side of the led which is the outside pad
