Hello I have just finished my third R-Jtag install on a Falcon. I have tuned it and gotten it to boot within 10 seconds. The only issue with this is once it boots up I can be on the dashboard for hours without it freezing but as soon as I eject the console completely freezes up. I think it has something to do with the image since it doesn't freeze until I hit eject. I am working on getting close up pictures right now. I used Jrunner to build a 16547 JTAG image WITH aud_clamp.

I also do not have my logs. Something went wrong and they were erased

crazed-cracker

crazed-cracker

VIP Member
Dec 10, 2011
224
23
OR
http://i787.photobucket.com/albums/...5-A625-47BC-B175-585CAB77E4EF_zps36drizbd.jpg

http://i787.photobucket.com/albums/...1-849C-49D1-938C-71AA2FB1EF03_zpsjlpwulyc.jpg

http://i787.photobucket.com/albums/...6-CD74-421C-B9F0-8DC7D37A8AB4_zpscptbzlic.jpg

http://i787.photobucket.com/albums/...E-1F32-40D6-8916-9CD2916D77C9_zpslbpb3lp6.jpg

http://i787.photobucket.com/albums/...4-EB45-4A3B-9AEA-734E468B23C2_zpsh9qz63f3.jpg

I have also tried all the different power settings on the actual R-Jtag chip

G

gavin_darkglide

VIP Member
Dec 14, 2012
2,303
118
have u tried adjusting power config in the smc? this was an issue with rgh2 on falcons. search in the coolrunner section.

xzanox

xzanox

VIP Member
Nov 1, 2011
905
48
Netherlands, 1336
I had to change only one time the SMC on a falcon rjtag for freezing, but that froze randomly, never only like you describe when hitting eject, so I wonder if it will solve you problem. But worth trying.

crazed-cracker

crazed-cracker

VIP Member
Dec 10, 2011
224
23
OR
gavin_darkglide said:
have u tried adjusting power config in the smc? this was an issue with rgh2 on falcons. search in the coolrunner section.
Click to expand...
Whats that the third console youve helped me fix? haha
I changed the SMC-Config to 8080 and sure enough it fixed the issue no freezing anywhere.
