FlashBIOS ISO Pre-Packed + Instructions

Xecuter

Staff member
Top TX Brass
Dec 6, 2002
11,468
128
Asia
team-xecuter.com
FlashBIOS v3.01 (256k + 256k) (Bank1 X2) (Banks 1&2 X3)
FlashBIOS v3.03 (256k + 256k) (Bank2 X2) (Banks 3&4 X3)
Includes 100MB Dummy File

Recommend you burn to a DVD-R (Ritek DYE)
Will work with some CD-R / CD-RW

http://www.teamxecuter.com/downloads/flashbios_iso.rar

Unpack the file with winrar v3.xx
http://www.teamxecuter.com/unrar/

Now burn the ISO to DVD - here is how....

Use Nero Burning ROM Version 5.x /6.x
Launch Nero.
Choose File, Burn Image and you'll be presented with a dialog box.
Click on the Files of type: dropdown box and select All Files (*.*).
Select the .ISO file you downloaded then press Open.

Next, Nero will show another dialog box of CD burning options. Accept the defaults:
Type of Image: Data Mode 1
Block size (Bytes): 2048
Image header (Bytes): 0
Image trailer (Bytes): 0)

Choose OK.
The Write CD dialog box should appear next.
Make sure Write, Finalize CD, and Disc-At-Once are checked, then choose Write.

Tips:

You must use the “Finalize CD” and “Disc-At-Once” option in Nero, or you will get the error: "FATAL ERROR: Installation of side by side assemblies failed" during setup.

You must specify *.* for the file type to see the .ISO file.


asdfasdf1

Junior Member
Dec 27, 2003
24
0
ROL Mod

well i got my 0603 SMD leds in the mail today. Only experience soldering was replacing the battery on my ipod nano, so wish me luck. Will post picture of results


TheMask

Senior Member
Dec 27, 2003
179
0
Re: ROL Mod

are you changing the controller ROL or the consoles? Because i failed miserably at changing, my controllers LED's!


gdaug112

Full Member
Dec 29, 2003
66
0
Re: ROL Mod

Check this out for the console ROL:

http://www.niktronixonline.com/Articles.asp?ID=137

Check this out for the controller ROL:

http://www.niktronixonline.com/Articles.asp?ID=133

It gives a lot of very good techniques for doing these mods and many have used it with great success. Let me know if you have questions.


asdfasdf1

Junior Member
Dec 27, 2003
24
0
Re: ROL Mod





Done. It took some patience, but wasnt too difficult. Anyone thinking about doing it may want to practice before, or have a extra RF module like i did.
