Has any one on here tried this on a Jasper yet? I thought I would give it a try on one I have with no key, all I am getting is a blank screen and flashing power light.
GENERAL Glitch on Jasper
- Thread starter Avinitlarge
- Start date
Everything is done, the CMOD programmed easily, nand written to, wiring done. I used the best pig ecc generator to create the ecc file.
I used this CMOD and followed the wiring diagram in the listing http://www.ebay.co.uk/itm/Glitch-Bo...&otn=4&po=LVI&ps=63&clkid=2794758363165640309
I used this CMOD and followed the wiring diagram in the listing http://www.ebay.co.uk/itm/Glitch-Bo...&otn=4&po=LVI&ps=63&clkid=2794758363165640309
aw man....that's gonna be hard to trace isn't it lol.....I'm thinking the wiring/soldering...if u had no issues with the reading, and writing etc......
start of with the simple bits...all resisitors removed that were supposed to be removed.....all bridges complete on the CMOD.....and no shorts......I know it's noob stuff, but u gotta start somewhere right lol....failing that is there any possibility of pics?
start of with the simple bits...all resisitors removed that were supposed to be removed.....all bridges complete on the CMOD.....and no shorts......I know it's noob stuff, but u gotta start somewhere right lol....failing that is there any possibility of pics?
Ive gone over and over it. Even removed everything and started again. Flashed the nand back to std, written a new ECC the wrote it to the nand, programmed the cmod again but nothing.
- Jun 4, 2010
- 3,080
- 0
Just tried with Exploit 360, still the same. I know the wiring on the mobo is ok but something it telling me its the cmod thats the problem
You do know that Bestpig's ECC generator doesn't work correctly with generating ECC for the original Xbox360....right?
I didn't, I thought it was the slim it didn't work correctly with. Im stuck, not sure which way to turn now. Im going to go over everything again later
Anyway if you say you used Exploit 360 and it still doesn't work, then the ECC probably isn't the problem.
jtag360.nl
VIP Member
With the C-Mod you must remove the Resistor R2 and connect R2's upper pad to R1's lower pad.
I do not see that on your picture.
I hope it helps.
I do not see that on your picture.
I hope it helps.
Right, just gone over everything twice, all the wiring is 100%. Ive programmed the cmod yet again but this time I did a readback and compared it to the original jed, loads of difference. I don't know if this if normal or not though
