ANSWERED Help! JF and Slim Kamikaze Winbond Unlock

N

NathhanRodz

Noob Account
Jun 3, 2012
8
0
Hello i just tryed to do this and its ****ed i think

JF Log

JungleFlasher 0.1.90 Beta (292)

Session Started Sun Jun 03 18:45:27 2012



This is a Wow 64 process running on 4 x 64 bit CPUs

portio64.sys Driver Installed

portio64.sys Driver Started, thanks Schtrom !

Found 4 I/O Ports.

Found 1 Com Ports.

Found 4 windows drives C: D: E: F:

Found 2 CD/DVD drives D: F:





No Drive Detected! DVDkey files extraction aborted!



Drive is Slim Lite-On..

Drive is Slim Lite-On..





0000: 05 80 00 32 5B 00 00 00 - 50 4C 44 53 20 20 20 20 ...2[...PLDS

0010: 44 47 2D 31 36 44 34 53 - 20 20 20 20 20 20 20 20 DG-16D4S

0020: 30 32 37 32 00 00 00 00 - 00 00 00 00 00 00 00 00 0272............

0030: 00 00 00 00 41 30 41 30 - 00 00 00 00 00 00 00 00 ....A0A0........

0040: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0050: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0060: 44 37 31 31 43 47 30 31 - 31 38 30 35 30 30 34 51 D711CG011805004Q

0070: 42 20 20 20 B



Sending Vendor Intro to port 0xF500



Serial flash found with Status 0x72



Sending Device ID request to port 0xF500

Manufacturer ID: 0xEF

Device ID: 0x11

Flash Name: Winbond/NEX(W25P20/NX25P20)

Flash Size: 262144 bytes

............

Key: CEB7F71AF788B7CE82E8D7E5B98A37E6 is verified, Thanks C4eva



Grabbing Key sector: ................

Key Sector verified.

Grabbing Serial info: ........



Drive is Slim Lite-On..

Key data saved to C:\Users\Nathan\Documents\Xbox\Flashing Stuff\Drive Keys\Slim Key\Key.bin



0000: 05 80 00 32 5B 00 00 00 - 50 4C 44 53 20 20 20 20 ...2[...PLDS

0010: 44 47 2D 31 36 44 34 53 - 20 20 20 20 20 20 20 20 DG-16D4S

0020: 30 32 37 32 00 00 00 00 - 00 00 00 00 00 00 00 00 0272............

0030: 00 00 00 00 41 30 41 30 - 00 00 00 00 00 00 00 00 ....A0A0........

0040: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0050: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0060: 44 37 31 31 43 47 30 31 - 31 38 30 35 30 30 34 51 D711CG011805004Q

0070: 42 20 20 20 B



Inquiry String saved to C:\Users\Nathan\Documents\Xbox\Flashing Stuff\Drive Keys\Slim Key\Inquiry.bin



0000: C0 85 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0010: 00 00 00 00 37 44 31 31 - 47 43 31 30 38 31 35 30 ....7D11GC108150

0020: 30 30 51 34 00 42 00 00 - 00 00 00 00 00 00 32 30 00Q4.B........20

0030: 32 37 20 20 20 20 4C 50 - 53 44 20 20 20 20 47 44 27 LPSD GD

0040: 31 2D 44 36 53 34 20 20 - 20 20 20 20 20 20 00 00 1-D6S4 ..

0050: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0060: 00 00 00 0F 00 40 00 04 - 00 02 06 00 00 00 00 00 [email protected]

0070: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0080: 03 00 78 00 78 00 78 00 - 78 00 00 00 00 00 00 00 ..x.x.x.x.......

0090: 00 00 F8 00 10 02 00 00 - 02 02 00 00 60 00 40 00 ............`[email protected]

00A0: F8 00 10 02 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

00B0: 3F 20 00 00 ? ..



Identify String saved to C:\Users\Nathan\Documents\Xbox\Flashing Stuff\Drive Keys\Slim Key\Identify.bin



0000: 44 37 31 31 43 47 30 31 - 31 38 30 35 30 30 34 51 D711CG011805004Q

0010: 42 20 20 20 FF FF FF FF - 30 43 31 33 30 32 39 30 B ....0C130290

0020: 31 36 36 33 31 35 58 58 - 41 30 FF FF 53 34 50 30 166315XXA0..S4P0

0030: 33 30 39 30 30 30 30 30 - 30 30 37 32 39 32 00 00 30900000007292..

0040: 00 00 00 00 00 00 00 00 - 00 00 00 00 41 30 FF FF ............A0..



Serial String saved to C:\Users\Nathan\Documents\Xbox\Flashing Stuff\Drive Keys\Slim Key\Serial.bin



Hashing Drive: ................



Dummy.bin file saved to Dummy.bin

Loading firmware from buffer

Inquiry string found

Identify string found

Drive key @ 0xA030 CEB7F71AF788B7CE82E8D7E5B98A37E6

Firmware Osig: [PLDS DG-16D4S 0272]

Firmware is: SlimKey Extract

Key added to database



Drive is Slim Lite-On..



Key found in KeyDB at record (5 - Slim Key)

Key is: CEB7F71AF788B7CE82E8D7E5B98A37E6

Key has been tested and verified, thanks C4eva !

Sending Vendor Intro to port 0xF500

Status 0x51

Re-sending Vendor Intro:

........................................................................................................................................................................................................

Device Intro failed!

Sending Vendor Intro to port 0xF500

Status 0x80

Re-sending Vendor Intro:

....

Serial flash found with Status 0x72



Sending Device ID request to port 0xF500

Spi Status: 0xFF

Manufacturer ID: 0xFF

Device ID: 0xFF

Flash Name: Unknown type

Flash Size: n/a

Sending Vendor Intro to port 0xF500



Serial flash found with Status 0x72



Sending Device ID request to port 0xF500

Spi Status: 0xFF

Manufacturer ID: 0xFF

Device ID: 0xFF

Flash Name: Unknown type

Flash Size: n/a

Sending Vendor Outro to port 0xF500

N

NathhanRodz

Noob Account
Jun 3, 2012
8
0
dgenx said:
try intro it..or lite on erase..if you have your dummy file
Click to expand...
i did the Liteon Erase and it says

Sending Lite-On-Erase request to port 0xF500
..............
Drive returned Status 0x7F
....................
Device Intro failed!

yes i did power it off then on

hersheys247

hersheys247

VIP Member
Dec 25, 2011
1,128
88
Detroit area, MI, USA
Sorry, but holly $hit that's a big hole

You can see the trace, does the DVD even still work


Sent from my Brain Tumor causing Device using Tapatalk

Please give Thanks and Rep if I have helped you

  • Like
Reactions: NathhanRodz
N

NathhanRodz

Noob Account
Jun 3, 2012
8
0
hersheys247 said:
Sorry, but holly $hit that's a big hole

You can see the trace, does the DVD even still work


Sent from my Brain Tumor causing Device using Tapatalk

Please give Thanks and Rep if I have helped you
Click to expand...

:/ Think im going to buy and unlocked PCB :L would that work if i install that?

hersheys247

hersheys247

VIP Member
Dec 25, 2011
1,128
88
Detroit area, MI, USA
Yes sir, make sure you have the DVD key saved safe and you will be good to go

Just write the DVD key to unlocked tx PCb and ur good


Sent from my Brain Tumor causing Device using Tapatalk

Please give Thanks and Rep if I have helped you

N

NathhanRodz

Noob Account
Jun 3, 2012
8
0
hersheys247 said:
Yes sir, make sure you have the DVD key saved safe and you will be good to go

Just write the DVD key to unlocked tx PCb and ur good


Sent from my Brain Tumor causing Device using Tapatalk

Please give Thanks and Rep if I have helped you
Click to expand...

Okay Thanks :) i can ge just a normal unlocked one for £32 or shall i get the Tx One for £40?

hersheys247

hersheys247

VIP Member
Dec 25, 2011
1,128
88
Detroit area, MI, USA
Same Difference!


Sent from my Brain Tumor causing Device using Tapatalk

Please give Thanks and Rep if I have helped you

T

turny

VIP Member
Mar 17, 2010
104
0
#JungleFlasher
your problem is not using a x360usbpro,
time and time again people disregard this advice,
get a x360usbpro
you should be able to recover the old pcb with badflash slim recovery technique
x360usbpro should be able to recover the old pcb on its own,or at worst with the aid
of a probe3 or a needle connected to ground.
Purchasing a new pcb will help only temporary,
you will probably be able to intro and vendor a blank pcb but once it has fw on it will be another ball game.
to the ppl suggesting liteon erase commands these dont work with slim drives btw.
