J-Runner (Device Not Found)

alzaabi

alzaabi

BANNED
Jun 11, 2011
18
0
1- QSB is installed
2- Coolrunner is installed
3- All Cables are conneced to the QSB and the Coolrunner
4- Green and Red lamps are working

but J-Runner says (Device Not Found)

I have Windows 7 Enterprise updated x64



---------- Post added at 00:46 ---------- Previous post was at 00:42 ----------

I forget the power is connected and the Xbox 360 is not turned on ...

X

XJonnyGunsX

VIP Member
Dec 2, 2011
175
48
Arizona - Upstate, NY
www.JonnyGuns.com
alzaabi said:
1- QSB is installed
2- Coolrunner is installed
3- All Cables are conneced to the QSB and the Coolrunner
4- Green and Red lamps are working

but J-Runner says (Device Not Found)

I have Windows 7 Enterprise updated x64

Link To Image
Click to expand...
Are you trying to read the NAND or program the Coolrunner?

From what you have stated with the Coolrunner's green light being lit, it still needs to be programmed.

What, of the two, are you trying to do right now?

EDIT: Oh! I didn't see your additional info hiding out in the bottom of your post. Did you get it sorted already, or you just stating that it was also plugged in?

Last edited:
MANUMAN

MANUMAN

VIP Member
Jun 11, 2011
591
0
DUBLIN
one of your points where you connect the nand x to read the nand is not soldered correctly. there are 10 points on your qsb that it could be. go back and check them all with a magnifing glass. i had this problem 2 hours ago. now i m on glitched dash 14719

A

AteOeight

VIP Member
Feb 22, 2012
278
0
Hawaii
Could you please post pictures of your soldering. Can be one of two things, either your Nand-X is on its last leg, or(and I hate to assume this) it's your soldering... the "not detected error is common for weak solder points.

X

XJonnyGunsX

VIP Member
Dec 2, 2011
175
48
Arizona - Upstate, NY
www.JonnyGuns.com
What the other gentlemen said about it being a solder issue, yes.

I've had it where everything looks fine from afar, but "in the beginning" I have had to retouch on all my QSB points. Lack of flux will make it a chore to get everything done the first time too.

Pictures would be very helpful for further diagnosis. :)

Last edited:
oO Elite Oo

oO Elite Oo

VIP Member
Sep 3, 2011
1,837
0
In your Nand
Device not found is connection error. You will need to provide your soldering connection as this will resolve this issue further more if you havent installed the driver for the Nand X then you will need to.

A

AteOeight

VIP Member
Feb 22, 2012
278
0
Hawaii
IMO, your soldering is fine! Maybe try another Nand-X, as mine was barely used, and it's on it's way out.

X

XJonnyGunsX

VIP Member
Dec 2, 2011
175
48
Arizona - Upstate, NY
www.JonnyGuns.com
alzaabi said:
Link To Image

Link To Image
Click to expand...

I would agree that the soldering looks good.

As o0 Elite 0o has stated, have you installed your NAND-X drivers? If not, this is your issue.

When I get discouraged with anything software/hardware related; I unplug everything, restart the computer, plug in the Xbox, and then plug in the NAND-X.

EDIT: Sorry, AteOeight! I didn't see your post. I see that's what your doing now.(diagnosing installed drivers) :)

Last edited:
axee44

axee44

VIP Member
Nov 8, 2011
330
48
York,UK
Soldering may look decent, but it doesn't mean it is good.
Only way to exclude soldering issue is to check with multimeter for continuity and i'd reccomend doing that before you start doing anything else.

  • Like
Reactions: XJonnyGunsX
X

XJonnyGunsX

VIP Member
Dec 2, 2011
175
48
Arizona - Upstate, NY
www.JonnyGuns.com
alzaabi said:
I updated my Nand-X Drivers again
and the J-runner says "Can not continue"

Link To Image

Link To Image
Click to expand...
Anytime I accidentally shorted a NAND-X point somewheres, it would throw me a "can not continue."

As axee44 has stated, It may look fine, but re-check all your points and underneath your board too.

I had a rare case of solder building up on the NAND points underneath the motherboard and somehow I had whisker-like shorts underneath. (This was a wired install and only happened once.)

Unfortunately, this all points to a short somewheres in your soldering.

alzaabi

alzaabi

BANNED
Jun 11, 2011
18
0
Does your console still power on?
Have you read my NAND-x troubleshooting guide?
Click to expand...
"Ididn't power on my console i just pluged in the power .. not turning it on
and i havent read the NAND-x troubleshooting guide ....
