RGH Jasper 512mb cb6751 won't glitch

V

viper0831

Full Member
Aug 19, 2009
63
0
Re-installed everything, I have the same results. The green light flashes 1-3 times and then stops, no xell though. I also tried with 2 of the caps in the cr package in parallel. Also with the inline cap on the d pad.

Martin C

Martin C

VIP Member
Jan 10, 2004
35,981
0
Scotland, UK
www.team-xecuter.com
viper0831 said:
That what I figured and have been using.

I'm starting over now from scratch. I removed everything, cleaned up the board, and reflashed the orig nand. It's booting that way, so in all of this at least the board is still fine.

In the meantime I got my falcon all wired up and done in less than 15 minutes.
Click to expand...
Is it still booting with the original NAND flashed to it?

If so, pack it up and send to someone to do it for you, or leave it as a stock console. Jaspers can be tricky and if you continue to flail around in the dark like you are, you WILL kill it.

V

viper0831

Full Member
Aug 19, 2009
63
0
Martin C said:
Is it still booting with the original NAND flashed to it?
Click to expand...
Yes it is still booting just fine with orig nand. The only reason I wanted to get this jasper done was that it was givin to me after a buddy screwed the board on the dvd trying to mra himself. It's been sitting in my basement for almost a year.

jtag360.nl said:
He already did that.


I (like more people) had also trouble with one Jasper BB.

Than I played around with the CPU_RST cable(blue) and some cap's, but no luck.

So I solder a thicker blue cable, and is booting perfectly now.

Off course all the Jaspers got there own problems.

Succes.
Click to expand...
I thought about trying different cables, but I only had thinner kynar right now.

Last edited:
V

viper0831

Full Member
Aug 19, 2009
63
0
Martin C said:
Then send it to someone to get the DVD key for you.

Not a hard choice considering.
Click to expand...
From your response to a different thread, I tried booting with the orig nand with the cr on, I get 2-3 green flashes and the it boot the orig nand. That should mean that the cr and soldering are correct? If so could it be an error with the ecc file or creation?

Martin C

Martin C

VIP Member
Jan 10, 2004
35,981
0
Scotland, UK
www.team-xecuter.com
viper0831 said:
From your response to a different thread, I tried booting with the orig nand with the cr on, I get 2-3 green flashes and the it boot the orig nand. That should mean that the cr and soldering are correct? If so could it be an error with the ecc file or creation?
Click to expand...
Possibly, yes.

What are you using to create the ecc?

V

viper0831

Full Member
Aug 19, 2009
63
0
I have been using multibuilder 0.7. I also tried jtag tool, but then the green flashes forever with no boot on orig nand either.

Martin C

Martin C

VIP Member
Jan 10, 2004
35,981
0
Scotland, UK
www.team-xecuter.com
Have you checked you solder points for continuity?

Do you have the 68nF cap installed?

Can you post your log from the ecc image creation?

marcosgue

marcosgue

BANNED
Nov 23, 2010
39
0
First sorry for my bad english.

I have the same problem, i try everithing that you guys recommended in this post and it's impossible...

i'm working in a Jasper 512Mb CB6751

now i'm going to try with a thicker blue wire.

If you find a solution please put in here!!!

Thanks
