RGH jrunner can not continue ???

[johannlynx]

'took off the cables' could have meant unplugging the NAND-x from the console (using QSB or pinheader). It's too generic and we kinda assume you're following a guide of sorts and understand the the .ecc is written to the NAND.

sorry my bad

now i have another problem.

i plugged the xbox but doesnt boot.

now the green light on the xbox flashes but there's no signal to the tv nor anything happens.

what should i do ?



[superspeed]

sorry my bad

now i have another problem.

i plugged the xbox but doesnt boot.

now the green light on the xbox flashes but there's no signal to the tv nor anything happens.

what should i do ?

If you haven't written to the nand you need to set the CR to prgm.



[Martin C]

2 threads and three pages later, I think it's a good time to post pics of all soldering and wire locations.



[johannlynx]

2 threads and three pages later, I think it's a good time to post pics of all soldering and wire locations.

please let me know what should i do to fix or continue and make my xbox boot.

thanks



[Martin C]

Pics should include your coolrunner and wiring layout.



[Dark_Riku]

The joints aren't looking too healthy there..



[johannlynx]

Pics should include your coolrunner and wiring layout.



[Martin C]

ok - bridge the point on the Coolrunner labelled 'cap'. It enabled the 68nF cap on board. You probably need it as it's a Jasper.



[superspeed]

I assume at this point you've written the .ecc to the console and if thats the case you can flip the switch on the CR to nor.



[johannlynx]

ok - bridge the point on the Coolrunner labelled 'cap'. It enabled the 68nF cap on board. You probably need it as it's a Jasper.

bridged it but still it doesn't boot in to xell nor in to anything. the green light in the middle blips.

the lights on the coolrunner are off

I assume at this point you've written the .ecc to the console and if thats the case you can flip the switch on the CR to nor.

yes i already wrote the .ecc and i haven't flipped the switch.

ps. just flipped it and a red light turned on in the coolrunner. is that bad ?



[superspeed]

bridged it but still it doesn't boot in to xell nor in to anything. the green light in the middle blips.

the lights on the coolrunner are off



yes i already wrote the .ecc and i haven't flipped the switch.

ps. just flipped it and a red light turned on in the coolrunner. is that bad ?

No that's not bad just means it has power. Now try booting the console and see if the green light blinks.



[johannlynx]

No that's not bad just means it has power. Now try booting the console and see if the green light blinks.

it blinked 3 or 4 times with a difference of 5 secs aprox then the last time it blinked twice and didn't turn on anymore.

still the xbox doesn't boot

now the coolrunner has the red light on and the xbox the blinking green light in the middle



[Martin C]

You might have to fix that STBY_CLK better, meaning soldering directly from the trailing trace to the resistor, then using the alt. point for the Coolrunner.



[johannlynx]

You might have to fix that STBY_CLK better, meaning soldering directly from the trailing trace to the resistor, then using the alt. point for the Coolrunner.

but before i wrote the .ecc to the nand was still booting.

i will try to fix it with the scrapping but i never got an answer if i should scrap over the copper line or only next to it ?

thanks again for all the answers and sorry that i messed up :frown:



[krypt1c]

Are you booting the console using the eject button?



[johannlynx]

Are you booting the console using the eject button?

no, i put the panel and turn it on from the boton on the middle , why ?



[krypt1c]

to get to xell you need to power the console on with the eject button.



[johannlynx]

to get to xell you need to power the console on with the eject button.

thanks man !!!!!!!!!
it booted in to xell, i'm glad it's late here and i didn't start to repair the lifted trace again.

i'm so happy

thanks again !!!!

:smile:



[krypt1c]

No problem , go to bed and sort the rest out when you have had a sleep:smile:

thanks man !!!!!!!!!
it booted in to xell, i'm glad it's late here and i didn't start to repair the lifted trace again.

i'm so happy

thanks again !!!!

:smile:



[Dark_Riku]

Don't ya just love a happy ending hehe, you go through all that messing around to find out it was a simple issue.
