Kprobe Liteon Burn Quality Testing Tool

F

fastford

Full Member
Nov 11, 2010
35
0
manchester uk
no probs uber ill get it re uploaded for you give me a few mins

---------- Post added at 12:52 ---------- Previous post was at 12:47 ----------
Ubergeek said:
This is really shocking to me as that media code is quite cheap and nasty, yet these numbers are really good. I'd like to see the graph image.
Click to expand...


i a going to test a different xgd3 backup i am just waiting for it to finish as soon as it it done ill post results

L

linnx88

Full Member
Apr 8, 2003
90
0
USA
Hmm just ran Nero DiscSpeed 5 and got great results for my Forza 2 disc 1 burn, better than in KProbe for some reason.

KProbe gave me like 1 9 PIF spike, DiscSpeed shows max as 4.

Take a look, i'm posting KProbe for the same disc for comparison, all done at fixed 4x speed.

Last edited:
P

psygenius

Junior Member
May 25, 2011
13
0
Ok here are my results; I burned a Verbatim MKM-003 and an AONE RICOH-JPN-D01C with the following settings:

DRIVER SAN FRANCISCO
OPC ON
Burn Speed 4x
Verified Successfully.

And here are my graphs:

Verbatim MKM-003:


+

AONE RICOH-JPN-D01C:


:).

Sprig

P

Phantasm606

Junior Member
Jul 14, 2003
11
0
USA
MEMOREX
BURN SPEED 4X
BF3 DISC 2
VERIFIED 100%

Date : 10/23/2011 4:29:33 PM
Model : 2-0-1-0 D:ATAPI iHAS124 B AL0S
Disc : DVD+R DL , MBIPG101R10A [Moser Baer India Limited]
Speed : 4x
ECC blocks sum (PI/PIF) : 8/1
Scanned range : 0 - 4267016
Sampling count : 244310
Errors : 0
PI Max : 150
PI Average : 33.47
PI Total : 1047023
PIF Max : 6
PIF Average : 0.24
PIF Total : 7503

Last edited:
S

swan.bag

VIP Member
Mar 3, 2011
203
0
In The Shed
Phantasm606 said:
MEMOREX
BURN SPEED 4X
BF3 DISC 2
VERIFIED 100%

Date : 10/23/2011 4:29:33 PM
Model : 2-0-1-0 D:ATAPI iHAS124 B AL0S
Disc : DVD+R DL , MBIPG101R10A [Moser Baer India Limited]
Speed : 4x
ECC blocks sum (PI/PIF) : 8/1
Scanned range : 0 - 4267016
Sampling count : 244310
Errors : 0
PI Max : 150
PI Average : 33.47
PI Total : 1047023
PIF Max : 6
PIF Average : 0.24
PIF Total : 7503
Click to expand...
I cant believe all the Battlefield 3 burns when it's not released yet :facepalm::facepalm:

X

Xmods

VIP Member
Dec 9, 2002
1,431
0
iHAS124 B opc on 4x burn

Date : 10/23/2011 2:33:40 PM
Model : 4-0-2-0 D:ATAPI iHAS124 B AL0S
Disc : DVD+R DL , [email protected] [UME Disc Ltd.]
Speed : 4x
ECC blocks sum (PI/PIF) : 8/1
Scanned range : 0 - 4267008
Sampling count : 249028
Errors : 0
PI Max : 431
PI Average : 16.81
PI Total : 524228
PIF Max : 32
PIF Average : 0.82
PIF Total : 25485





cross flashed to iHAS624 B opc on 4x burn

Date : 10/23/2011 4:32:38 PM
Model : 3-1-0-0 D:ATAPI iHAS624 B GL29
Disc : DVD+R DL , [email protected] [UME Disc Ltd.]
Speed : 4x
ECC blocks sum (PI/PIF) : 8/1
Scanned range : 0 - 4267008
Sampling count : 250686
Errors : 0
PI Max : 85
PI Average : 19.73
PI Total : 618547
PIF Max : 13
PIF Average : 0.79
PIF Total : 24619








more tests to come

Last edited:
M

mathesar

Junior Member
Jul 31, 2010
10
0
California
I'm getting pretty bad results compared to others but so far every disc verifies 100% in Imgburn and installs to 360 HD no problem.

Burned @ 2.4X / No OPC


M

Mister_X

VIP Member
Apr 13, 2011
189
0
Canada
linnx88 said:
Hmm just ran Nero DiscSpeed 5 and got great results for my Forza 2 disc 1 burn, better than in KProbe for some reason.

KProbe gave me like 1 9 PIF spike, DiscSpeed shows max as 4.

Take a look, i'm posting KProbe for the same disc for comparison, all done at fixed 4x speed.
Click to expand...
Those nero results are both below what is considered a good burn. it has been stated the disk quality score must be 93% or higher to be considered a good burn.

M

Minne

Full Member
Oct 13, 2011
63
0


here is my battlefield disc 2. even though its a 5 it's still in good shape and safe right?

Last edited:
A

astr4twin

Full Member
Nov 28, 2010
77
0
Again burnt using Aone DL Printable (Ricoh JPND01-67)

burnt at 2.4x after changing in MediaCodeSpeedEdit with OPC set to on.

Quite alot better than Forza burn which scored a PI of 142 and PIF of 3



Uploaded with ImageShack.us

H

hiker13526

Junior Member
Oct 12, 2011
10
0
Can people please list where they bought the media as well, and if it was bought online a direct link to the product page?

I need to buy better media ASAP -_-

Last edited:
L

linnx88

Full Member
Apr 8, 2003
90
0
USA
Mister_X said:
Those nero results are both below what is considered a good burn. it has been stated the disk quality score must be 93% or higher to be considered a good burn.
Click to expand...
Doesn't matter what nero score is considered. It's simply the combination of PI/PIF errors.

My PI is perfect, my PIF is well within range, 2 mods and people on #c4e said I had good burns. Look at uber geek's 2nd burn, and he calls that perfect, he has 1 9 PIF spike, one 7 spike and one 6 PIF spikes.

The nero results are consistent with KProbe +/- 1

All my games passed imgburn verify, kprobe, nero and installed on xbox. Playing now, no problems whatsoever with Dark Souls nor Forza 4.

J

jivex5k

Full Member
Dec 20, 2004
46
0
NC
deose said:
Verbatim MKM001 - OPC - X2.4 - ImgBurn
Link To Image

hmmm, anyone know why second half is so high on PI?
Click to expand...
I'm having the same issues on the same setup. Looks like 001s on the 124 series have a decent chance of higher PIs than the 003s burnt on the same drives.
I posted my results some pages back but they are similar and worse in the case of Dark Souls.
I've got some 003s ordered that should be here in a week, it seems like they are consistently solid more than the 001s on 124 drives.

EDIT: Here's my latest RAGE scan. I don't know if i'm doing something wrong or what but it looks pretty bad:

Last edited:
