Kprobe Liteon Burn Quality Testing Tool

I

ideloera

Full Member
Oct 12, 2011
73
0
Chicago
GoW 3

Smartburn = enabled
Force Hyper Tuning = disabled
Online Hyper Tuning = disabled
Connected via USB 5.25 enclosure

ImgBurn
Burned 2.4x
OPC Disabled
Verbatim MKM001


Last edited:
suntu ieu

suntu ieu

VIP Member
Nov 27, 2010
159
0
München


Forza cd 1

External PSU, X360UsbPro, Verbatim mkm 003 @ 4x(opc enabled) ... 324b drive

Smartburn = enabled
Force Hyper Tuning = enabled
Online Hyper Tuning = enabled

K

KevinNash

Junior Member
Feb 20, 2011
11
0
France
linnx88 said:
It's still a crappy burn. Your PI max is too high, > 100, an d your PI avg > 5, 25 is way too many errors on every scan.

See OPs first post.

This would score about a 50-60% in Nero DiscSpeed.
Click to expand...
I agree but it's better than put them in the trashcan.

XGD2 is dead and this discs are for my Xbox backups only, so... At this time my Xbox wants to read them, I am glad with this.

A

alyshehata

VIP Member
Jan 26, 2011
377
0
2.4x OPC off EEPROM all enabled except Over Speed Burn 324B >> 524B



4X OPC On EEPROM all enabled 324B >> 524B



4X OPC On EEPROM default 324B >> 124B



No idea whats up with the spikess

Last edited:
L

linnx88

Full Member
Apr 8, 2003
90
0
USA
KevinNash said:
I agree but it's better than put them in the trashcan.

XGD2 is dead and this discs are for my Xbox backups only, so... At this time my Xbox wants to read them, I am glad with this.
Click to expand...
It might seem so at first. But, if you're going on xbox live, Micr$oft can, if they haven't already, do a check for quality response. If your disc fails that check, that's a possible ban flag.

Pressed, retail discs have very low PI/PIF rate if any.

I'm not saying it'll happen or you'll get banned today or tomorrow, but there is a large chance since they CAN do it, so your only question should be, "When will they?".

R

RockWolf

Noob Account
Sep 13, 2005
5
0
Belgium
It won't get much better than this :)

MKM003, burned at 4x with OPC enabled. All the rest is default settings in IMGBURN.

External power, USB-to-SATA converter used to connect Liteon iHAS624 B to my laptop


Last edited:
R

RockWolf

Noob Account
Sep 13, 2005
5
0
Belgium
linnx88 said:
No it won't! :cool:

Please post EEPROM settings.

One thing I definitely noticed, as somebody above have already mentioned, the MKM003s seem to produce MUCH better burns than MKM001s!

Will be getting them after I run out of 001s. Got 15 more left though :(
Click to expand...
Didn't touch any EEPROM setting, standard flash.

And yes it's true, MKM003's produce better burns than MKM001's. I tried the same game on MKM001 and it had much higher PI rates compared to MKM003. Especially on L1.

Last edited:
I

ideloera

Full Member
Oct 12, 2011
73
0
Chicago
Battlefield 3 and Batman AC (respectively)

Smartburn = enabled
Force Hyper Tuning = disabled
Online Hyper Tuning = disabled
Connected via USB 5.25 enclosure

ImgBurn
Burned 2.4x
OPC Disabled
Verbatim MKM001






M

mrtvgame

Noob Account
Mar 20, 2006
1
0
Yeah, after installing Kprobe it just crashes my system with one of those nice blue screens. wtf!?

Is the Nero test suffice?

E

exeron

Noob Account
Feb 7, 2011
5
0
XGD3
Smartburn = enabled
Force Hyper Tuning = enabled
Online Hyper Tuning = enabled
Connected via x360usb pro

ImgBurn
Burned 4x
OPC = enabled
BURN-Proof = disabled


Last edited:
B

bounceman99

Full Member
Jan 31, 2011
40
8
Austria
I got some strange results on K-Probe, why strange?
i'll tell you ...

First Burn:
MKM003 @4x, OPC enabled, ImgBurn 100% verified
good K-Probe, but doesn't work on console (stuck during loading screens, then "This disc is unreadable")




Second Burn (because first stuck on console again and again despite good K-Probe)
MKM003 @2,4x, OPC disabled, ImgBurn 100% verified
bad bad K-Probe but is working fine so far on console



Isn't it strange, that the good burn doesn't work on console, but the bad one works fine???

Has anyone any thoughts about that??

Thx in advance :)

Last edited:
x360ccm

x360ccm

BANNED
Jan 18, 2011
3,616
0
south coast UK
my second burn

EEPROM Settings
Smartburn = enabled
Force Hyper Tuning = disabled
Online Hyper Tuning = disabled

IMGBURN settings
OPC = Enabled
Burn Speed = 4x
Verify 100%
Nero Score = 64
SATA Chipset = onboard ati




third burn same settings as above

EEPROM Settings
Smartburn = enabled
Force Hyper Tuning = disabled
Online Hyper Tuning = disabled

IMGBURN settings
OPC = Enabled
Burn Speed = 4x
Verify 100%
Nero Score = 0
SATA Chipset = onboard ati



fourth burn change the settings in imgburn after the third result

EEPROM Settings
Smartburn = enabled
Force Hyper Tuning = disabled
Online Hyper Tuning = disabled

IMGBURN settings
OPC = Enabled
Smartburn = enabled
Force Hyper Tuning = enabled
Online Hyper Tuning = enabled
Burn Speed = 4x
Verify 100%
Nero Score = 95
SATA Chipset = onboard ati



Last edited:
  • Like
Reactions: ezzda1
