[JoinX]

Yeah that sounds pretty plausible

Ah well, we'll see if the solders stays intact or not


And for those who are STILL wondering if the fibreglass scratch pen is necessary - YES IT IS.
It does wonder



[ricky38570]

Re: Open tray error.

Connectivity Kit Pro CK3 4. and and the ck3 Probe 1
it sure be here in a day or to i have a liteon 7485c drive never been flash
is it ok to remove the ribbon before i try to get the dvd keys then put it
back on went it is flash this is my frist one to flash i hope this is the right place to asked
i am trying to do this for my grandson i would love to hear from any one on here that would help me out here thanks



[BGAMods]

ok so you will be attempting to flash the liteon 74850. all you need to do is probe the r707 hole on the drive and follow the tutorial. i assume the ribbon you are referring to is the laser ribbon? its recommended to remove this as its widely thought that leaving this connected whilst flashing the liteon can lead to the open tray error. if im mistaken then let me know and ill help you out some more.



[ricky38570]

am sorry it is a liteon 74850c so it is ok to take the ribbon off frist and then follow the tutorial yes laser ribbon is what i am talking a bout thabks



[modmonster]

Yeah. Just remove the laser ribbon.
Make sure when you put it back, you take your time and don't damage the contacts on the end.



[BGAMods]

as mod said be careful when removing the ribbon and putting it back in. they are easily damaged if youre not careful.



[ricky38570]

ok thanks for helping me out i will do that



[BGAMods]

no probs and remember to hit the thanks button when people help.



[lookwhos]

i have a question when you first sucessfully flash your lite-on 74850c by using the blaster + probe and when you put everything together and want to flash to 0800 fw to rip games.... do you have to take apart the xbox to dis connect the laser ribbon everytime you want to upgrade ?
<!-- / message -->



[BGAMods]

that would totally defeat the purpose of having the blaster. the laser ribbon theory is just that ... A THEORY.
ive flashed about 100 liteon drives and never had any issue with the laser and ive never bothered to unplug cause i personally think its a myth.



[lookwhos]

thanks for the fast reply i will press the big thanks button!
and is the lastest fw for liteon the ix 1.1 safe for xbox live?



[BGAMods]

no probs mate and yes it is reported as safe for live, but of course this rely's on all your backups being fully stealthed.



[yoyo50]

My mate got all his stuff yesterday and attempted his first key extraction, but somehow he said that smoke/spark came from the black chip near the 07 point.

When he put it back together it had rrod, and he didn't even get the key!

So is his pcb dead? or is there some fix you can do with that chip?

Cheers.



[modmonster]

Yeah you have to send it to a professional. Theres nothing you or your friend can do unfortunatley. As your in the uk, send it to TeaJunkie or Flashing360. They'll sort it out.
Either send them a PM or use the request a service at the bottom of the home page.



[ricky38570]

like to say thanks flash my frist one on trobble at all ok so you will be attempting to flash the liteon 74850c. all you need to do is probe the r707 hole on the drive and follow the tutorial. i assume the ribbon you are referring to is the laser ribbon? its recommended to remove this as its widely thought that leaving this connected whilst flashing the liteon can lead to the open tray error. if im mistaken then let me know and ill help you out some more.



[lookwhos]

i sucessfully flashed my lite-on drive using the blaster 360 i sucessfully burned a copy of mw2 and when i put the disc inside and load it...it would load from the hard drive and when i press eject on the blaster the disc comes out and im still able to play off the hard drive with no disc. i was wondering if this is safe... thanks for all the great guides this was my first flash!



[modmonster]

The game only needs to be in the drive to start the game. If you try to start it from the HD without the game in the xbox it won't work.



[danandrews80]

Hi

I just thought I would check here as this seems to be the main tutorial. Is it important that I remove the ribbon as stated in this post
http://www.team-xecuter.com/forums/showpost.php?p=256221&postcount=9
Or is it ok to do it exactly as this tutorial says

Thanks in advance



[modmonster]

Although its never been proven that leaving the laser ribbon in causes the laser to possibly burn out, its still thought to be good practice and its better to be safe than sorry.
Personally I remove them but there's loads of guys that never do.
It's up to you, but for 10th seconds work, I'd say its worth removing it.



[BGAMods]

id never removed a laser ribbon until recently. ive never had a laser issue after but didnt want to damage a customers drive and end up losing money so i do now just to be careful.
