GENERAL Monitor COM with usb to serial cable

[Aiosforos]

hello guys, i have one cable usb to serial db9 and im thinking to make a com monitor cable for coronas,

can someone tell me wich pins are RX and TX of this screen?

http://www.xecuter.com/forums/attachment.php?attachmentid=9794&d=1341855417



[Krafter]

2 = RX 3 = TX.


Sent from my iPhone using Tapatalk



[rdubbs007]

Why not just get a corona qsb and use the nandx to usb cable?

Sent from my Galaxy Nexus using Tapatalk 2



[Aiosforos]

thanks a lot Krafter, i dont buy them because i already have the cable, theres no reason to spent money



[stefanounick]

especially with Greece's current state..



[n0syst3m]

Use a nokia DKU-2 instead

Edit: DKU-5 Cable not the DKU-2



[haxork]

Has anyone tried to use a Ca-42 cable. I have one but not sure if it will work. I have no issues trying it as long as someone gives me a heads up on where to wire the 3 wires. It is a prolific chip if anyone is curious.

Thanks



[BL4K3Y]

Has anyone tried to use a Ca-42 cable. I have one but not sure if it will work. I have no issues trying it as long as someone gives me a heads up on where to wire the 3 wires. It is a prolific chip if anyone is curious.

That cable should work fine - see this image.



[haxork]

thanks BL4K3Y, I was looking at the jrunner guide again and noticed that the nandx cable and usbprov2 Tx,Rx are switched. Im assuming I wire it up like the Nandx to usb correct?

Thanks



[Xecuter]

thanks a lot Krafter, i dont buy them because i already have the cable, theres no reason to spent money

Top left of your screen

what is the full name of this website ?



[Aiosforos]

hey guys i think ill need some help again, i use the cable correct and proper soldered and when console glitches etc i see on monitor com the xell info with no proper letters

is it the font or anything?



[Netkar]

Please post photos



[Krafter]

hey guys i think ill need some help again, i use the cable correct and proper soldered and when console glitches etc i see on monitor com the xell info with no proper letters

is it the font or anything?


Link To Image

Corona? I had the exact same problem. I left it on for a couple of hours and came back to scan the IP and the key popped in. You might try the same.

I think Xell is trying to load but its getting hung up on something. Maybe trying to acquire an IP?



[Aiosforos]

well everything seems to be put in place, im a bit tired today and i might be doing some stupid error, check it out too, i cant be that blind

heres the pinout too



[Krafter]

What happens if you scan for an IP?



[Aiosforos]

scan for ip when i have monitor com open? i havent tried it, should i?



[Krafter]

I'm just asking what happens when you scan for an IP? It doesn't matter if the comm window is open or not.



[Aiosforos]

Nand Initialization Finished
Tip: Load the nand on source to have quicker results.
Scanning.......
No Xbox Detected
Finished



[Antalpromille]

I think the problem is that you need a ttl converter. The update cable is usb to rs232 ttl, or at least i thinkt it is, i updated my nand-x using a rs232 ttl cable from ftdi.
Google it, there are some easy solutions on DIY versions.



[Aiosforos]

hmm the cable i have is rs232, i need to mod it?
