Hey guys just finish rgh'N my slim trinity
Everything is good but takes about 4 minutes to boot. N when it boots it shuts off after 3 minutes. Heres some pics of my work .please dont judge its my first time soldering and first time rgh'N a console.
I went in to xex menu and cpu was at 53.2 and gpu was 50.0 but it went up to 50.2 and then it shuts off. Dont kno if it has anything to do with it, but just thought yah should kno. And dont worry about the colors. There all mixed but there in the right place.
And for stby_clk (point B) I used alternative FT3N2
Im thinking its my ground cable...







HACKING XBOX 1

HACKING XBOX 1

Junior Member
Nov 26, 2013
17
0
c and b looks like there touching and the legs on ur wires are 2 long u need to clean it up and trim wires/ ft4r2 u need to resolder that and make sure its on the pad its touching another point
