need help with nad-x wires install

[stonislandmodz]

need help with nad-x wires install pics uploaded

ok so i solder the wires direct to the mother board but i have burnt one r more of the traces on the j1d2and may of bunt a tarce on j2b1is there any wa can fix this and i will try and get pictures up as son as i can but my camrea has broke so n for repairs also its a xenn mother board and if ythere is a diffrent way i can dump the nand can you put ptures with coulored lines of what wires go where

thanks

i have attached some pictures of the problem hope this can help you out with resoleving it

[spoil]

[/spoil]



[manwithoutname]

Just flip the board and solder to the alternative points at the back that's of course assuming that there is no damage has occurred beyond the soldering points on top.



[stonislandmodz]

i tryed this and i stil get a message saying can find usb or somthing along them lines



[manwithoutname]

Try this thread by xmods it might help you ...



[stonislandmodz]

i dnt understand it what coulor wires go where



[J2G]

Have a read through these bro i think you might have rushed into it before knowing how to do it right ..

UPDATED NAND/JTAG SOFTWARE TUTORIAL *JULY 9th 2010*

Alternate JTAG SMC/Points Tutorial

Official JTAG Tool Thread



[jorgesalas831]

If you havent burned a lot of the trace you can get an exacto knive and scrape a little bit off to expose the unburned trace and repair it with a conductive pen or make sure your solder touches the trace.



[Xmods]

if you can post me hi res pic i can tell you what you need to do to repair it



[stonislandmodz]

black lines ive added is were the traces are burnt



[jorgesalas831]

so which is the trace that is burned?the little squiggly lines on the left?



[stonislandmodz]

yh the sqigly lines are the ones i added



[Xmods]

those have to be repaired for the console to work they are super small if you haven't noticed they connect you nand to your southbridge without them being repaired the console will never work



[stonislandmodz]

the console turns on fine but when i try to dump the nand it says carnt recingise flaash device
