RGH Phat RGH not working coolrunner green light doesn't flash

[jack mack]

So any Phat RGH i've attempted has failed with the same error (except one Phat) the problem is that i start it and for a split second the coolrunner flashes then stops or it flashes irregularly when i try to boot to xell and it never boots soldering pics below

And the rest are attached



[manwithoutname]

Lift the green wire of the board and see if it works, if that fails redo the green wire point but try to make it aligns horizontally and not vertically like in your current picture.



[axee44]

Solder your CPU_RST to where it should be. You have soldered it to wrong pad



[crono1000]

I'd also run the blue under the board and away from those coils. That is an area known for interference.

Sent from my LG-P999 using Tapatalk 2



[crono1000]

Also, where do you have gnd soldered? Maybe I can't see it cause I'm on my phone, but it doesn't seem to be where most people connect it. Without that the green wont blink.

Sent from my LG-P999 using Tapatalk 2



[theboyfromthemoon]

solder here



[Mister_X]

post_out (yellow) looks like it may be shorting as well. cpu_pll_bypass looks ot be shorted (green) CPU_rst (blue) is soldered to the wrong pad and the joint looks cruddy.



[kingadent]

apparently this "soldering" guy i used to solder them all may have F'ed them up but my slims work fine i'll re solder them myself.

---------- Post added at 23:20 ---------- Previous post was at 23:19 ----------

i'm posting from my friend's account BTW



[GamingRepairs]

If green light dont blink that means it has something to do with soldering.



[Kr4k 4 J4Ck]

apparently this "soldering" guy i used to solder them all may have F'ed them up but my slims work fine i'll re solder them myself.

---------- Post added at 23:20 ---------- Previous post was at 23:19 ----------

i'm posting from my friend's account BTW

Do not attempt to do this yourself if you don't have the skills required, you don't want to mess the board up.



[kingadent]

my soldering skills are perfectly fine as i said All my 13 slims work just perfect.



[GamingRepairs]

Ive soldered alot of consoles there's always something you mess upon. Slims and phats are different. Check your soldering add solder to all the points. Once you have done that proceed .
