Please Help, Falcon Wont Glitch.

L

LukeD

Noob Account
Apr 12, 2010
3
0
I've got a falcon and have been trying to get it to glitch all day, and it is driving me mad. I dumped the nand three times and they all matched however there were 2 bad blocks. I checked the dump in 360 flash tool and it reported that the bad blocks were -> Block ID 0x0267 found @ 0x3FE and Block ID 0x018c found @ 0x3ff.

I then went on to create an ecc image with jtag tool, all went fine, i then wrote it to the nand and then went to try it out however the xbox would not glitch. The red and green light are both on and the green light flashes off every 5 seconds or so when the fans change speed. It will continuously do this and wont boot.

The coolrunner is flashed with the falcon file and the wires avoid the coils on the motherboard. I also tried remapping the bad blocks because it wouldn't work and i thought it might be that but, i still couldn't seem to get it to work though, i probably didn't remap it correcty anyway. Is it because of these bad blocks?

Has anyone got any ideas???

Thanks for any help

L

LukeD

Noob Account
Apr 12, 2010
3
0
Thanks i'll try that now, with xnand healer what file do i use for the "NAND image to be remapped", i have loaded the nand dump i made into the "original nand nand image containing bad blocks" box.

Here are the pictures of the wiring










Last edited:
Goldensavage

Goldensavage

VIP Member
Jul 26, 2009
3,332
0
Essex, UK
Yellow wire on the wrong point....

Should be on FT6U7.... Should always check wiring...



Also your Point B, seems wonky compared to the pic and the way mine turn out. Notice the QSB cuts the R4B25 writing in half. Yours is completely visable. Seems off kilter


Last edited:
L

LukeD

Noob Account
Apr 12, 2010
3
0
Thank you, i don't know how i missed that, i thought i did check but obviously not properly. Its now working.

Thanks so much.
