Post your DemoN install pictures here!

[Aaronmaster69]

lookin great guys heres mine.never mind cant get them to upload. ill try later.



[Aaronmaster69]

i dont know how you get them to show without clicking on them but here they are.



[DavGerm4]

@Aaronmaster69 looks good! I wish I could still solder the small points, but can't anymore ! Anyways, loving the pics, makes me excited to get mine installed!



[Avinitlarge]

Ive had mine a week and only just got round to fitting it, it was a piece of piss, fired it up and it worked spot on 1st time. I replace the coolrunner that I fitted last year with a REV C whilst I was at it



[tusel]

I had no problem installing demon Slim - just couple of tips:

PCB is quite large so you better use piece of both-sided sticky tape to hold it in place (pic 1) to prevent miss-alignment

View attachment 9589

I tend to clean, flux and pre-tint points before (pic2)

View attachment 9590

Points are smaller, but with a little patience the are easy to do (pic 3,4). There is no need to change to smaller solder tip,just steady hands and patience

View attachment 9591
View attachment 9592

Thanks for this great product, another success !

View attachment 9593



[Xmarksthesh0t]

Tusel cannot see pics, please try replouad and thanks for the tips.



[jimlfixit]

Hi guy, I don't have a demon yet, but decided to route the wires on a pic without needing to jump across other wires and also for a neater install. Anyway here is my take on the wiring.

This routing may or may not be possible as i dont know the length of the wires, however some wire stripping may be required.



[jimlfixit]



[WNYConsoles]

This is my standard DemoN/Slim installation method now...

Full gallery @ http://wnyconsoleservices.com/photogallery/index.php/Slim-RGH-DemoN-Install



[shakezilla]

very nice work im hoping to get mine done wed or thurs when im off from work.



[DavGerm4]

This is my standard DemoN/Slim installation method now...

Link To Image

Full gallery @ http://wnyconsoleservices.com/photogallery/index.php/Slim-RGH-DemoN-Install

Very nice install, very clean, I love it!!! Mine was sent to a professional to install it! I can't solder those small points anymore .

Anyways great pics guys! And Tusel, I can't see your pics either.



[tusel]

Very nice install, very clean, I love it!!! Mine was sent to a professional to install it! I can't solder those small points anymore .

Anyways great pics guys! And Tusel, I can't see your pics either.

Strange i can see the pics just fine, will try to reupload anyway or any mod can kindly fix that for me.

EDIT : Pics Reuploaded, hope its ok now



[TheGlow]

Strange i can see the pics just fine, will try to reupload anyway or any mod can kindly fix that for me.

EDIT : Pics Reuploaded, hope its ok now

Ahh I see them, the links aren't underline or anything. Mouse over and click. I can't even middle click to open in tab in Firefox.



[Jos Dekker]

Good advice, its changing my way of work!



[darix]

my install of Demon



[darix]

ok



[coolshrimp]

Pictures of my first install. Works Perfect.

Demon Slim & Cool-Runner REV.B



Quick Solder Points (Sorry bad pic)

Very Fine Tip Iron (Weller)

Quick Solder Points

Wires To Console

Wires To Console

Wires & Quick SOlder Points

Wires Including Power and Sync

Coolrunner REV.B (Wire To LEG For Power On)

USB Port & Switch



[aids76]

Hi all !
Demon just open another world for me
Thank you Xecuter,you are my hero

My installation pics :



[Gogu]

My pictures with Demon installed :biggrin:



[Gogu]

My others pictures with Demon installed. Demon works perfectly. Thanks Xecuter :biggrin:
