Post your DemoN install pictures here!

Hugox

Hugox

Full Member
Dec 2, 2011
27
0
Pics of my demon install. Soldered with fine soldering tip 18 watts.

Before:




After:












Install works 100%. Glitch times could be better though. Around 5-8 cycles of green average. Don't like the coax wire because it ripped of my solderpoint once.

B

blober54

Junior Member
May 3, 2010
16
0
Oregon, USA
www.electronicsrenew.com
trippy86 said:
at last, someone who has brains and doesnt cover their joints in glue but used tape

I salute you
Click to expand...
Thank you sir, I always use electrical tape when I do my installs, have a roll sitting by my soldering iron all the time lol.... helps insure when theirs issues it cant be grounding out, but if it is you will see it since the tape will have a wire poking through lol

K

koetjuh

Senior Member
Dec 17, 2011
110
0
NL
Jasper SB.
Used double shielded cable first, but it didn't glitch so I replaced CPU_RST with the slim cable. Boots now in 20-55 seconds. Also used QSB v2, that is why i2C_SCL and SDA are soldered underneath the mb.

S

SOD_FrosT

VIP Member
May 14, 2012
361
0
Presque Isle, ME
Im so juiced. These all look so awesome. I can't wait to get my DemoN installed in my Elite. Need to get it shipped off to LoneWolf so he can stop staring at my DemoN and actually put it in the console. :D

X

X-b0n3z

Junior Member
Sep 18, 2005
17
0
Orange, CA
Here is my trinity GoW Demon with CoolRunner rev C. I decided to dremel a very thin slot for the Demon USB board. I then drilled a very small hole for the GND.

-b0n3z

(click image for HUGE pics)
