Retail boots fine, getting e-71 or e-79 error

[kordris]

Hello there, I doing this trinity mb with a CR pro and Demon. I have retail side booting with no problem. But the demon side I having the two error codes depend what I try with the final image. I have some bad blocks on the motherboard its self and there's some bad blocks on the demon as well. From what I had read its probley something to do with these bad blocks and how I doing the writing the final image. This first demon I have done that has given me this problem so I guess its time to learn about bad blocks and how to get around them etc.. I have pictures of the install I just need to get them off my camera. Also have my jrunner log also. When I get the e-71 error is when I do get the rgh side to boot into fsd. Then I try to go the regular dashboard through the center button on the controller then selecting system. It then goes to the e-71 error and get a red dot on the Ring of lights. Then when I try to take the image and not use the demon/fusion remap option and load that image I get E-79 error when it finally glitches. Any help would be nice, thanks.

 ===================================================Thursday, July 31, 2014 7:02:10 PM


J-Runner v0.3 Beta (4) Started




WARNING! - Your selected working directory already contains files!
You can view these files by using 'Show Working Folder' Button




Checking Files
Finished Checking Files
Initializing nanddump1.bin..
Trinity
RGH2 Selected
Nand Initialization Finished
Initializing updflash.bin..
Trinity
Nand Initialization Finished
Options.ini file was altered successfully
Use Edited Options Selected
Options.ini file was altered successfully
Current: DemoN
Switching to XBOX
Current: XBOX
Switching to DemoN
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F 0x3FF
Writing Nand
Done!
in 0:32 min:sec


Options.ini file was altered successfully
Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Options.ini file was altered successfully
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Done!
in 0:32 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Options.ini file was altered successfully
Use Edited Options Selected
Retail Selected
Using edited settings
Load Files Initiliazation Finished
16756
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_glitch.ini
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_jtag.ini
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_glitch2.ini
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_glitch2m.ini
Started Creation of the 16756 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building retail image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16756.0
Console   : Trinity
NAND size : 16MiB
Build     : Retail
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
RGH2 Selected
Nand Initialization Finished
Current: DemoN
Switching to XBOX
XBOX360
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x7320 ST Micro (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C
Writing Nand
Done!
in 0:33 min:sec


Current: XBOX
Switching to DemoN
Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Options.ini file was altered successfully
Use Edited Options Selected
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
XBOX360
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x7320 ST Micro (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C
Writing Nand
Done!
in 0:32 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
XBOX360
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x7320 ST Micro (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C
Writing Nand
Done!
in 0:32 min:sec


Retail Selected
Load Files Initiliazation Finished
16756
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_glitch.ini
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_jtag.ini
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_glitch2.ini
Couldn't add dashlaunch patches to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild\16756\_glitch2m.ini
Started Creation of the 16756 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building retail image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16756.0
Console   : Trinity
NAND size : 16MiB
Build     : Retail
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
RGH2 Selected
Nand Initialization Finished
XBOX360
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x7320 ST Micro (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C
Writing Nand
Done!
in 0:32 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Current: XBOX
Switching to DemoN
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x22F
Writing Nand
Starting remapping process
Remapping Block 0x22F @ 0x3FF
Done!
in 0:36 min:sec


DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Done!
in 0:31 min:sec


Options.ini file was altered successfully
Use Edited Options Selected
Options.ini file was altered successfully
Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Done!
in 0:31 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x22F
Writing Nand
Starting remapping process
Remapping Block 0x22F @ 0x3FF
Done!
in 0:32 min:sec


Options.ini file was altered successfully
Use Edited Options Selected
Use Edited Options de-Selected
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Done!
in 0:32 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Current: DemoN
Switching to XBOX
Current: XBOX
Switching to DemoN
Options.ini file was altered successfully
Use Edited Options Selected
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Done!
in 0:32 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Options.ini file was altered successfully
Use Edited Options Selected
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x22F
Writing Nand
Done!
in 0:31 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Starting remapping process
Remapping Block 0x12C @ 0x3FF
Remapping Block 0x22F @ 0x3FE
Done!
in 0:32 min:sec


Options.ini file was altered successfully
Use Edited Options Selected
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F 0x3FF
Writing Nand
Done!
in 0:32 min:sec


Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Done!
in 0:31 min:sec


Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Starting remapping process
Remapping Block 0x12C @ 0x3FF
Remapping Block 0x22F @ 0x3FE
Done!
in 0:31 min:sec


Options.ini file was altered successfully
Use Edited Options Selected
Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F 0x3FF
Writing Nand
Starting remapping process
Remapping Block 0x12C @ 0x3FF
Remapping Block 0x22F @ 0x3FE
Remapping Block 0x3FF @ 0x3FD
Done!
in 0:32 min:sec


DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x22F
Writing Nand
Done!
in 0:31 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
DEMON
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x22F
Writing Nand
Done!
in 0:31 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F
Writing Nand
Starting remapping process
Remapping Block 0x12C @ 0x3FF
Remapping Block 0x22F @ 0x3FE
Done!
in 0:31 min:sec


Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F 0x3FF
Writing Nand
Starting remapping process
Remapping Block 0x12C @ 0x3FF
Remapping Block 0x22F @ 0x3FE
Remapping Block 0x3FF @ 0x3FD
Done!
in 0:32 min:sec


Initializing nanddump2.bin..
Trinity
Nand Initialization Finished
Options.ini file was altered successfully
Use Edited Options Selected
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x12C 0x22F 0x3FF
Writing Nand
Starting remapping process
Remapping Block 0x12C @ 0x3FF
Remapping Block 0x22F @ 0x3FE
Remapping Block 0x3FF @ 0x3FD
Done!
in 0:32 min:sec



[kordris]

These are also the bad blocks jrunner shows on the retail nand.

• Bad Block ID @ 0x12C [Offset: 0x4D5800]




• Bad Block ID @ 0x12C Found @ 0x3FF[Offset: 0x107BE00]



[alexander_1333]

Use noremap when you create the image then demon/fusion write.



[kordris]

I have tried that, It boots up and loads fsd. As soon as I got to mini blade and select the option to go into the regular dash to like load or format the hdd stuff like that. It goes to a red dot and E-71 error. Heres the log when I did what you said which I did before and same results.

Use Edited Options de-SelectedSaved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x22F
Writing Nand
Starting remapping process
Remapping Block 0x22F @ 0x3FF
Done!
in 0:31 min:sec



[Antalpromille]

Check and see If your dump is blank at 0x12c, if so you need the information on 0x3ff to put on 0x12c.
Otherwise jrunner will overwrite that information when it remap the bad block on your DemoN nand.



[kordris]

I got pictures now.. I had to find the cord to get them off the camera since I dont have a memory card reader. But these are the best pics. I took of every qsb points that I could.



[kordris]

Check and see If your dump is blank at 0x12c, if so you need the information on 0x3ff to put on 0x12c.
Otherwise jrunner will overwrite that information when it remap the bad block on your DemoN nand.

How to check to see if the dump is blank at 0x12c? Im sorry havent ever had to get this detailed in jrunner.



[kordris]

I did a dump of the retail with demon tools, this is the info.

***** NAND-Flash Information *****


Manufacturer:                Numonyx
Device:                      NAND128W3A
Device Id:                   0x2073
Number of Blocks:            1024
Number of Pages per Block:   32
Page Size:                   528 bytes
Number of Invalid Blocks:    1
Addresses of Invalid Blocks: 300


Full backup selected.
Reading.
Reading completed successfully in 23 seconds!



[nath247]

How to check to see if the dump is blank at 0x12c? Im sorry havent ever had to get this detailed in jrunner.

Load your NAND in J-Runner and go to Tools | Hex Editor.



[kordris]

I try to do that when I get a chance.... I'm working two jobs on weekend right now and just don't have time to spare to mess with till monday sometime. Im going to try sometime tomorrow if I can get then time. Thanks for reply.

What line is the 0x12c? what should it look like in hex editor 00000120? Sorry asking never had to get into this much detail of nands.



[kordris]

I used hex workshop and loaded the nand image and then used the goto and typed 0x12c and it took me to the right spot I guess... Which is 0000012b and then over two spaces which shows 00 and on far right is shows just .......... Am i in the right area and in the right area or right direction. Thanks again.



[kordris]

Is it normal to get a error when writing back to the nand on the xbox it self when theres bad blocks? I'm still trying to figure out why i getting the error code. If I don't put the fsd on the hdd or use a thumb drive to boot up with it automatically goes to e-79 error code. If I use the thumb or hdd to load the fsd on it. It will boot up and then If i try to go to the system menu I get the e71 error code.



[kordris]

When I read the nand I getting 3 bad blocks, but when I try to rewrite the nand with the glitch image It only shows remapping 2 blocks, could that be the problem?



[N.E.Modz]

When I read the nand I getting 3 bad blocks, but when I try to rewrite the nand with the glitch image It only shows remapping 2 blocks, could that be the problem?

Am I missing something here?? you say retail boots fine, but your having problems with demon fitted ? Surely this indicates something to do with the installation?

Jrunner will remap the bad blocks so unless there are loads of bad blocks (usually indicated by bad nand connections) then there should be no problems

Ive noticed on your pics that the yellow connection to the mobo looks dodgy to say the least and the red cable (unless its the reflection) does too.

i would check all your connections and re-do if necessary and try again

Just my opinion

dale:rolleyes2:



[jsinger47]

When I read the nand I getting 3 bad blocks, but when I try to rewrite the nand with the glitch image It only shows remapping 2 blocks, could that be the problem?

That sounds to me like you didn't build a "noremap" image.

So, in JR, go to the XB Settings tab. Hit "Advanced Xebuild Options," then tick the "noremap" button. After you hit OK, make sure the "use edited settings" button is checked.

Then create your RGH image. Then write it to the demon by hitting Advanced -> Demon/Fusion Write.



[kordris]

I have tried that several times, but I will try again. Ok, I get past the xbox logo screen then it goes to E-71 error screen. I did what you said. Heres the log for this last time.

Current: XBOX
Switching to DemoN
Initializing nanddump1.bin..
Trinity
Nand Initialization Finished
Initializing nanddump1(3).bin..
Trinity
Nand Initialization Finished
Options.ini file was altered successfully
Use Edited Options Selected
Using edited settings
Load Files Initiliazation Finished
16747
Started Creation of the 16747 xebuild image
KV Info saved to file
---------------------------------------------------------------
     xeBuild v1.12.659
---------------------------------------------------------------
base path changed to D:\Xbox stuff\J-Runner v03ld\J-Runner\xeBuild
---- { Image Build Mode } ----
building glitch2 image


---------------------------------------------------------------
C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505\updflash.bin image built, info:
---------------------------------------------------------------
Kernel    : 2.0.16747.0
Console   : Trinity
NAND size : 16MiB
Build     : Glitch (v2)
Xell      : power on console with console eject button
Serial    : 013832404505
ConsoleId : 030387615069
MoboSerial: 7256240202780455
Mfg Date  : 11/03/2010
CPU Key   : 48E2DB784B5DD2C9FDC2A91318C2251E
1BL Key   : DD88AD0C9ED669E7B56794FB68563EFA
DVD Key   : 2918F51DDA2E9B120CA55B5A358475B0
CF LDV    : 10
KV type   : type2 (hashed - unchecked, master key not available)
---------------------------------------------------------------
    xeBuild Finished. Have a nice day.
---------------------------------------------------------------
Use Edited Options de-Selected
Saved to C:\Users\Allen\Downloads\J-Runner v03ld\J-Runner\013832404505
Image is Ready
Initializing updflash.bin..
Trinity
Nand Initialization Finished
Hardware   : Demon Slim
Firmware   : 1.4
Flash ID   : 0x73AD Hynix (16MiB - Small block)
Flash Size : 0x400 blocks of 0x4200 bytes
Invalid Blocks : 0x22F
Writing Nand
Starting remapping process
Remapping Block 0x22F @ 0x3FF
Done!
in 0:31 min:sec



[playingmax]

try writing nand from xell. n see if that helps.



[kordris]

Am I missing something here?? you say retail boots fine, but your having problems with demon fitted ? Surely this indicates something to do with the installation?

Jrunner will remap the bad blocks so unless there are loads of bad blocks (usually indicated by bad nand connections) then there should be no problems

Ive noticed on your pics that the yellow connection to the mobo looks dodgy to say the least and the red cable (unless its the reflection) does too.

i would check all your connections and re-do if necessary and try again

Just my opinion

dale:rolleyes2:

I will try to clean the wire connections up to make sure. I might of already did it. Because i was trying to make sure it wasnt the connection.



[kordris]

try writing nand from xell. n see if that helps.

Tryed to write the upflash with xell, it shows 4 or 5 bad blocks.
0x10d
0x12c
0x195
0x22f
0x3ff
Not sure if that is solder problem or not.



[kordris]

Also when I do write with xell this time, it only shows two bad blocks. When It boots I get a screen that video locks up in bars and red light on the front panel comes on but no e- error.
