RGH Jasper Help

D

Dont Trip Noob

Full Member
Jan 14, 2012
79
0
Ok i have done other RGHack consoles but this jasper wont boot into Xell Reloaded afteri flashed the .ecc file i am thinking its the Point by the HANA Chip Cuz this jasper did not have any solder on the points but i really don't know this is a 16MB Jasper not a BB Can anyone help O PS the when i try to boot the red light stays on like is should do and the green blinks every 5secs

-DoC-

-DoC-

VIP Member
Jul 23, 2004
682
48
US
Sounds like it could be the wiring if you were able to read and write the nand.

Post up some pics of the soldering.

TilVl

TilVl

VIP Member
May 11, 2011
1,383
0
Did you bridge the Cap on your coolrunner? (For Rev B) Pics of install and wire routing would help as well.

D

Dont Trip Noob

Full Member
Jan 14, 2012
79
0
-DoC- said:
Sounds like it could be the wiring if you were able to read and write the nand.

Post up some pics of the soldering.
Click to expand...
Lol its not my wiring

---------- Post added at 21:28 ---------- Previous post was at 21:25 ----------
TilVl said:
Did you bridge the Cap on your coolrunner? (For Rev B) Pics of install and wire routing would help as well.
Click to expand...
No i did not bridge nothing cuz when i have done other RGHacks they boot fine as is

TilVl

TilVl

VIP Member
May 11, 2011
1,383
0
Well Bridge the two points on your coolrunner that says "CAP" if you have Rev B.

Also we're trying to help. Don't be a douche. It very well could be your wiring and if you're so confident of your work please post so we can disregard the wiring.

If you would've read the tut Uber made for us you weill learn about the cap and that they help jasper boards boot.

D

Dont Trip Noob

Full Member
Jan 14, 2012
79
0
TilVl said:
Well Bridge the two points on your coolrunner that says "CAP" if you have Rev B.

Also we're trying to help. Don't be a douche. It very well could be your wiring and if you're so confident of your work please post so we can disregard the wiring.

If you would've read the tut Uber made for us you weill learn about the cap and that they help jasper boards boot.
Click to expand...
Just Bridged still no boot as you can see in this PIC some of the Points right next to the HANA Chip have no solder Now this Jasper had no Solder on none of them so i just put some on and put the wire on

J

Justice1231

VIP Member
May 4, 2011
1,005
0
Adelaide, Australia (down south)
Nope that looks fine. what your coolrunner light flashing or not?

Edit ignore the light flashing just read origianl post again.

Again jasper 16m can be a bit difficult to glitch try bridging the cap on the coolrunner, i know youve said youve done them before and there fine, so i have but ive did one the other day that was taking around 6 cycles to glitch (36 seconds), I bridged the cap and now its glitches within 10 secs most of the time.

Last edited:
D

Dont Trip Noob

Full Member
Jan 14, 2012
79
0
Justice1231 said:
Nope that looks fine. what your coolrunner light flashing or not?

Edit ignore the light flashing just read origianl post again.

Again jasper 16m can be a bit difficult to glitch try bridging the cap on the coolrunner, i know youve said youve done them before and there fine, so i have but ive did one the other day that was taking around 6 cycles to glitch (36 seconds), I bridged the cap and now its glitches within 10 secs most of the time.
Click to expand...
Ok got it to boot can i do anything so it can boot faster soldering?
