RROD 0032 *Demon Removed*

[coolshrimp]

I could not get the console to turn on after installing demon just made the ping sound.
checked all my points actually removed and reinstalled demon 3 times

i finally gave up and removed the demon on this one.
but now with stock console noting on it i get RROD 0032 it sometimes will start to boot show the logo half way thru trows the RROD.

i did not touch the nand as i could not get demon to read.
also as soon as i plug it in it comes on and starts to boot.

what to do next?

Console : Trinity 4GB



[BL4K3Y]

Post a photo showing FT4R2 or C5R11 please (it depends which CPU_RST point you used).

Is there continuity between the two points?



[coolshrimp]

USED: FT4R2



[coolshrimp]

yes there is continuity between the 2.



[coolshrimp]

it seems if i leave console unplugged for a while say 10-15 min it will boot or half way before RROD. then after that its instant RROD next time i try. let it sit again it will repeat the cycle.



[nofeloniesyet]

it seems if i leave console unplugged for a while say 10-15 min it will boot or half way before RROD. then after that its instant RROD next time i try. let it sit again it will repeat the cycle.

i see no damage to cpu rst line,which would cause 0032 or 0031 even.last 3 boxes i had here with 0032 and no damage to cpu rst turned out to be southbridge reballs/replaces.



[coolshrimp]

i see no damage to cpu rst line,which would cause 0032 or 0031 even.last 3 boxes i had here with 0032 and no damage to cpu rst turned out to be southbridge reballs/replaces.

yup seems like the issue i let console sit all night i tested this morning it ran for about 5-10min then rrod. so its def CPU or South-bridge not from my install



[nofeloniesyet]

yup seems like the issue i let console sit all night i tested this morning it ran for about 5-10min then rrod. so its def CPU or South-bridge not from my install

southbridge is most likley from the error code your getting.



[coolshrimp]

southbridge is most likley from the error code your getting.

FIXED wow was a tiny resistor under Xclamp that was damaged.

weird cause i never removed xclamp must have been previous owner as i got it used and it was opened before.
like image bellow not actual picture



[kdavids]

Oh my word, been searching for a fix to my 0032 error for days now and stumbled upon this, checked my board and BOOOM, exact same reason, exact same resistor, trick is, I've never removed the X-Clamp before checking. THANKS MAN!!!!



[nofeloniesyet]

Oh my word, been searching for a fix to my 0032 error for days now and stumbled upon this, checked my board and BOOOM, exact same reason, exact same resistor, trick is, I've never removed the X-Clamp before checking. THANKS MAN!!!!

glad ur both sorted,and didnt need sb replace.
