RGH Slim rgh no xell and NO Video

[desoto_mods]

Thats my theory as well.. its currently working fine with orig nand .. I used alt points last night with same results.. I know they split the cb on phats to stop or attempt to stop them from being tagged.. is it possible that something has been done on microsofts end to jack with these?

Ive done plenty of slims and jtags in general.. never have I seen or heard of such a thing.. I did have one that when building the ecc file.. something happened and gave a 1022 error.. rrod but still booted and worked fine..(phat) and rebuilding ecc from another program fixed that one.

Thanks again for the help.. hope someone can think of something I didnt



[Statecowboy]

"Also, can you post better close up shots for the top of the board and of the CPU_RST on the back?"

Can you do this?



[desoto_mods]

Heres the new pics.. let me know if you need more



[Statecowboy]

This looks a little sketchy, I assume you've checked them over?

Also, this is probably not an issue, but the way you routed your CPU_RST is a little odd in that the bare wire is resting (or bridged) to the bare pad beneath it...but like I said, doubt it's the issue.



[desoto_mods]

To all that helped I appreciate it.. after pulling everything back off of this motherboard, I started replacing each individual part and found the problem in the cpu-rst wire. Replaced it and it boots xell no problem...

Now on to the next project!!



[Statecowboy]

To all that helped I appreciate it.. after pulling everything back off of this motherboard, I started replacing each individual part and found the problem in the cpu-rst wire. Replaced it and it boots xell no problem...

Now on to the next project!!

Congrats man! Guess it was bridging huh?
