Slim Wont Boot Xell

[Statecowboy]

Hey guys, I have a Trinity that will not boot to Xell. I have never had a problem booting a slim to Xell before. I do have bad blocks at 3 and 37, but both nands read the same, so when I created the .ecc image J-Runner said it was remapping them. I suspect that may be the culprit? Here's my output log. Coolrunner does flash green trying to glitch, but just wont catch.

Initializing Nand..
Bad Block ID @ 0x0003 [Offset: 0xC600]
Bad Block ID @ 0x0037 [Offset: 0xE2E00]
Block ID 0003 Found @ 0x03FF [Offset: 0x107BE00]
Block ID 0037 Found @ 0x03FE [Offset: 0x1077C00]
Block ID 03FF [Offset: 0x107BE00] remapped to Block ID 0003 [Offset: 0xC600]
Block ID 03FE [Offset: 0x1077C00] remapped to Block ID 0037 [Offset: 0xE2E00]
Bad Blocks Remapped
* found flash image, unpacking....
ECC'ed - will unecc.
UnECC'ed
* found decrypted CD
* found XeLL binary, must be linked to 0x1c000000
* we found the following parts:
SMC: 3.1
CB_A: 9230
CB_B: 9230
CD (image): 9230
CD (decrypted): 8453
* this image will be valid *only* for: trinity (slim)
* patching SMC...
Patching Trinity version 3.1 SMC at offset 0x13B3
* XOR HACK NEEDED FOR CB System.Int32[]
* patching CB_B 9188...
patchset for 9188 found, 4 patch(es)
* Applying XOR Hack to CB_B System.Int32[]
*** Re-encrypting CB_B with xor keystream
*** Fixing entrypoint
* constructing new image...
* base size: 70000
* Replacing CB_A 9230 with 9188
* encrypting CB...
* No separate recovery Xell available!
* Flash Layout:
0x0..0x1FF (0x200 bytes) Header
0x200..0xFFF (0xE00 bytes) Padding
0x1000..0x3FFF (0x3000 bytes) SMC
0x4000..0x7FFF (0x4000 bytes) Keyvault
0x8000..0x9ABF (0x1AC0 bytes) CB_A 9230
0x9AC0..0x114EF (0x7A30 bytes) CB_B 9188
0x114F0..0x174EF (0x6000 bytes) CD 8453
0x174F0..0xBFFFF (0xA8B10 bytes) Padding
0xC0000..0xFFFFF (0x40000 bytes) Xell (backup)
0x100000..0x13FFFF (0x40000 bytes) Xell (main)
* Encoding ECC...
100%
------------- Written into output\image_00000000.ecc
Arm Version: 3
Flash Config: 0x00023010
Writing Nand
Error: 202 reading block 3
Error: 202 reading block 37
Done!
Exited!



[mm53668]

I don't think it works remaping the first 50 blocks as thats where Xell lives - I could be wrong though



[TilVl]

try remapping your blocks your self with nandpro.

Sent from my SGH-T839 using Tapatalk



[Statecowboy]

I don't think it works remaping the first 50 blocks as thats where Xell lives.

:eek2: damn.

Here are pics of the install anyway - if anyone has other ideas I'm all ears...

---------- Post added at 19:13 ---------- Previous post was at 19:06 ----------

try remapping your blocks your self with nandpro.

Sent from my SGH-T839 using Tapatalk

Not sure how to do that, I'll need to do some reading. Thanks for the tip.



[TilVl]

If you want to send me your nand ill try and remap them when I get home.

Sent from my SGH-T839 using Tapatalk



[Statecowboy]

If you want to send me your nand ill try and remap them when I get home.

Sent from my SGH-T839 using Tapatalk

PM sent, thanks in advance.



[WestCoastConsoles]

http://www.team-xecuter.com/forums/showthread.php?t=76014

Here's a good link for you.



[Statecowboy]

http://www.team-xecuter.com/forums/showthread.php?t=76014

Here's a good link for you.

This did the trick. Much appreciated.



[XL3THAL VIP3RX]

just use another ecc image made from the same rev mob,tht works



[Statecowboy]

just use another ecc image made from the same rev mob,tht works

Didnt even think of that, good point.
