SPUTNIK Probe Points

[Ubergeek]

Just intro the drive and a popup will ask if you want to unlock the spi

Cut the trace - click yes - probe the point - unlocked done. Solder the trace back together - continue with the flashing as usual.

This is what a trace cut should look like when done correctly and professionally. Traces cleaned with fiberglass scratch brush, trace cut then both side fluxed and tinned.

Note: the pic isn't the spot you need to do on the DG-16D4S board - its shown as an example



[lockpicker]

perfect uber thanks, if any1 cant follow that then somethings wrong



[sherlock]

if they can't follow that then they shouldn't be modding.



[Ubergeek]

Forgot to say, try 10ohms switch setting first.



[lockpicker]

is that the setting that we shud be using to gettin an unlock 1st time of many?



[sherlock]

sorry, still the same belief as my first post.:wink: after uber's added info.



[sherlock]

is that the setting that we shud be using to gettin an unlock 1st time of many?

i would say that's the starting point.



[slidder]

Thanks Uber



[J2G]

i would say that's the starting point.

With the setting at 10 Ohm its good to go :wink:



[ataroreh8132]

I have a question for anyone here, the tin on the trace are for to repair the trace afterward, right?



[djbeta66]

Yep!



[Ollie82]

If i have this item thats means i don't need to buy and use SPUTNIK360 unlock switch?



[GaittievO]

No you don't need it anymore.



[rodman55]

regular intro in jungleflasher???? thats the only part that is unclear to me



[sidearms]

If i have this item thats means i don't need to buy and use SPUTNIK360 unlock switch?

Sorry, what item? The probe3?

My 9504 is now 0272 w/ 13146 dashboard w/ 1.9 cfw. I know when I flash back to stock and update to 13599, the drive will lock.

I want to flash to 1.91 cfw. Do I need both probe3 and SPUTNIK360 unlock switch? Thanks.



[diaboliq20]

If u have MXIC then you EITHER need a Sputnik Probe OR the Sputnik switch - this tut is for points in the probe method

probe 3 is for phats, but can be used in some trouble shooting on slims afaik

of course if it's Winbond, it's good old kamikaze lol



[x360ccm]

Sorry, what item? The probe3?

My 9504 is now 0272 w/ 13146 dashboard w/ 1.9 cfw. I know when I flash back to stock and update to 13599, the drive will lock.

I want to flash to 1.91 cfw. Do I need both probe3 and SPUTNIK360 unlock switch? Thanks.

best thing to do is find out if you have a winbond board or a mxic board first.

hook it upto jungleflasher and that would tell you.

why not flash to 1.92 cfw instead of 1.91.



[sidearms]

Got a MXIC. Better to get the probe or the sputnik? And yes, CFW 1.92. Thanks.



[MightyModz]

Got a MXIC. Better to get the probe or the sputnik? And yes, CFW 1.92. Thanks.

if you are confident with your soldering skills then get the unlock switch, if your not too keen on soldering then the probe would be better for you. the switch is just more practical



[sidearms]

if you are confident with your soldering skills then get the unlock switch, if your not too keen on soldering then the probe would be better for you. the switch is just more practical

thanks. went with the probe. will just add a switch between the cut.
