Whats needed for this console?

[Morgiee101]

Thanks for your help guys got the stuff yesturday and done most of it no so far so good but those solder points are small and so close to each other! The hardest part was the demon and upgrade board merging those together. So now coming to the end of the install i have a few questions:

1. With the demon setup different to the other slim consoles having the extra pcb attatched and not being able to solder the big point next to the micro usb port does the wiring locations run the same as the trinity or is the wire locations differant on the v3 console?

2. with the cr3 pro installed do i insert the demon squere control bord to the falk pins on the cr3pro and do i wire the cr EN port from the square pcb to the coolrunner? or does the cr3 pro and the demon control this function via the provided ribon cable?

3. Once everythin is installed. I still havnt dumped the stock nand, decided to solder everything on first then dump the nand from the mini usb plug on back of console using j-runner ?

4. These are my next steps just need to make sure im correct before doing:

Dump 2 copies of the stock nand and compare, is both match with no errors then

Create glitch .eec from of of the stock nand images, xell, and write it back to the origional xbox nand?

Boot console and let it glitch to load xell and get cpu key and dvd drive key?

Erase and write stock nand back to xbox nand to boot back to normal, create the glitch files and re write the glitch nand image created to the demon nand

Test again and see if demon boots exploit nand image. Turn off flick the switch boot console and see it boots stock nand from the console

Final step follow the rater instructions to fine tune the glitch times? Could some explain it better what this stage is and how to do it as after reading into it and trying to digest it all its not sinking in. One min you have all dips on off then 3&4 is on then 10cf cap is installed.


Thanks



[Martin C]

You have a DemoN - there's absolutely no need to WRITE anything to your 360 NAND.

Once you've confirmed the DemoN NAND is booting from your good NAND dump, you do everything else on the DemoN NAND.



[Morgiee101]

Ah ok so the only thing you need from the xbox is the origional stock nand. The write the .ecc and created glitch files to the demon nand. As you boot the console and it glitches it will load from the demon nand. gotya, as far as the wiring is concerned now that i have installed the additional qsb under the demon is the wiring for the demon the same locations as the trinity and the TX installation guide? And lastly as far as the Rater is conserned are you able to explain it differantly as the guide goes into alot of details and dont know were to start, what settings to put the dips on or what caps i need to install. It tells you earlier in the guide to have all dips odd then later gives suggestion like dip 3 and 4 on with no cap and 5 points?

Just need the concept of the rater explaining a little better

Thanks



[Martin C]

Everything you need to know has been explained in enough detail in the guides and tutorials.
