JTAG wont boot dash ? after xell

[mafia 5k]

hi again , Today I am trying to jtag a xenon motherboard with 6717 dashboard and a CB 1903 , I managed to get my xell CPU key and followed with 12611 freeboot but i get a single green light and no picture nothing also tried xell and nothing so i install the virgin nand back and it works but freeboot wont any ideas?

oh, there were no bad blocks 3 out of 3 dumps all matched and i am using the 2diode jtag config



[seanr28]

what method of wiring are you using? Standard or alternavie method with Aud_clamp and Tray_open signal?



[mafia 5k]

what do you mean did you read the topic huh?



[seanr28]

yes I did, answer the question



[manwithoutname]

lol, told off by a newbie .. Sean how could he use alternate points of it's a xenon board?

mafia 5k, try recompiling freeboot however I don't know if this will make a difference considering that now even xell doesn't work. Recheck the jtag part install, if using QSB then try different resistor settings and if using just standard diodes then try replacing them.



[mafia 5k]

manwithoutname ,I dont know , I swapped out the diodes and recompiled freeboot and got dash working fine, Im wondering if it was the diodes or the freeboot nand hmmm...

sean, Thanks but you asked about the hdmi wiring and im jtagging a xenon using 2 diodes like i said from the beginning, I didnt mean to sound like a total ass sorry bro


here is a pic of the finished jtag"



[seanr28]

your right! sorry mate, missed the xenon bit.
