LITEON DG-16D2S Xbox 360 Will give me the "Extract Complete" prompt in JF but will fail afterwards

[shiffner]

Xbox 360 Will give me the "Extract Complete" prompt in JF but will fail afterwards

Some info before I begin:
Have an older XBOX 360. Liteon drive FW: 74850C. Updated my dashboard to current version so I'm thinking I am now at FW: 0251

Anyway. I am reading the JF tutorial EXTREMELY carefully. I get right up to the point of the "Extract Complete" dialog box after probing. Making very sure of the instructions in the dialog box and as well as what is stated in the JF tutorial and all that too. But it keeps saying "Phatkey failed"

Anyway, I'm really outta ideas here and I'm new to all of this stuff. I recorded my JF Log. It errors out as follows:

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
JungleFlasher 0.1.92 Beta (304)
Session Started Mon Feb 13 19:47:01 2012

This is a 32 bit process running on a 32 bit CPU
X360USB PRO detected, Version 0.18

Found 1 I/O Ports.
Found 1 Com Ports.
Found 3 windows drives C: F: Z:
Found 1 CD/DVD drives F:

Drive is Lite-On..
Sending Vendor Intro to port 0x0000
Status 0x51
Re-sending Vendor Intro:
..........................................
Serial flash found with Status 0x52

Extracted drive key failed Verification !


PhatKey extraction failed!

/end log

Any suggestions/help/ideas would be GREATLY appreciated. If this is a dumb or trivial question, my apologies in advance. Just need some help.

Thanks!

---------- Post added at 20:12 ---------- Previous post was at 20:10 ----------

One more bit of information and not sure if this helps or could be the issue but, I am using a KeyGrabber Pro w/ probe, to extract the key. I have struggled to find any documentation on this device (borrowed from a friend, who I might add, is equally stumped during this extraction)

Thanks!



[doe1200]

Re: Xbox 360 Will give me the "Extract Complete" prompt in JF but will fail afterward

when you get extract complete you will get a message saying remove probe then power off drive for 5 seconds ,then hit ok,when that message appears you can hold the probe button in for 5 seconds then let go, are turn off what ever you are using to power your drive for 5 seconds, power on then click ok



[shiffner]

Re: Xbox 360 Will give me the "Extract Complete" prompt in JF but will fail afterward

Yeah, I'm doing exactly that. It still says failed verification.

Just to clarify I am using a Keygrabber Pro, it has no button for the probe. However on the little chip, there's a switch to power the drive on and off. That is what I am using to power it on and off when prompted to.

Here is a picture of the hardware I'm using.
http://i102.photobucket.com/albums/m118/simont26/Armagh-20110831-00010.jpg



[shiffner]

Re: Xbox 360 Will give me the "Extract Complete" prompt in JF but will fail afterward

Welp. I just said screw it and bought the 15 dollar CK3 Probe 3. I imagine it will be a lot easier.

I guess this case is closed. :/



[x360ccm]

Re: Xbox 360 Will give me the "Extract Complete" prompt in JF but will fail afterward

you have a usbpro but no probe 3.

use the search tab,and you find your answer.

hint pmt:rolleyes2:
