Xbox Won't turn on

[matt2416]

So, I lifted the STBY_CLK pad by accident. :facepalm:
Since this the xbox has not been turning on, I cut the trace and soldered a wire to the place suggested, it still won't turn on. Also the resistors on the two rows above have come off, don't know how. Going to put this down to doing it so late as night, due to the amount of successful RGH's I have done.



[Indestructable]

either take it to a pro who can fix it or put it in the bin



[Martin C]

That's two consoles which two separate issues now.....

Aren't you better to just post in the 'request a service' section rather than asking for help here?



[matt2416]

That's two consoles which two separate issues now.....

Aren't you better to just post in the 'request a service' section rather than asking for help here?

As, I said in the other post, I don't have 25 posts yet, so it won't let me. Is there anyway you could grant me access?



[Martin C]

As, I said in the other post, I don't have 25 posts yet, so it won't let me. Is there anyway you could grant me access?

I've just seen that - apologies.

I've reported the post to an admin as I wasn't aware we were blocking posts in that section.

As I suggested in your other thread (which I've only just replied to), check my sig for price of repairs.



[snoop123]

Try this one workt for me

http://team-xecuter.com/forums/showthread.php?t=74992

And than the FT2R2 - Grey wire.

Greetz



[matt2416]

Try this one workt for me

http://team-xecuter.com/forums/showthread.php?t=74992

And than the FT2R2 - Grey wire.

Greetz

The coolrunner is removed and it stil won't turn on.



[snoop123]

The coolrunner is removed and it stil won't turn on.

I did this also with CR off and its boot up.
You have to take the red wire of.
solder a wire on the back of the risistor and the on the back off the mobo,
FT2R2 - Grey wire



[snoop123]

So you had to the grey wire attached when the CR was off?

no not on cr



[matt2416]

no not on cr

Ok and would those small bits above that aren't there stop it from turing on?



[snoop123]

Ok and would those small bits above that aren't there stop it from turing on?

yes that happend to me



[snoop123]

Do you have a backup mobo that is broken



[matt2416]

Do you have a backup mobo that is broken

Hmm, well I have a Slim that is hopefully getting fixed, so I really don't want to take stuf off that.



[snoop123]

Hmm, well I have a Slim that is hopefully getting fixed, so I really don't want to take stuf off that.

Well if you had one you could taken a risistor off it,
solder it between a wire an than solder it on the mobo.
Thats wath i did and workt for me.
just like you did with the red wire.
Bud then with a risistor solderd on it.



[matt2416]

Well if you had one you could taken a risistor off it,
solder it between a wire an than solder it on the mobo.
Thats wath i did and workt for me.
just like you did with the red wire.
Bud then with a risistor solderd on it.

Would this type of resistor work?



[snoop123]

Would this type of resistor work?
Link To Image

no its the little one where you have to solder the otherone on.
I add a picture and markt it black on the risistor.



[matt2416]

no its the little one where you have to solder the otherone on.
I add a picture and markt it black on the risistor.

Why would this not work and what else has these resistors in?



[DayvG]

The regular through hole resistors work fine but your best off replacing with a 33ohm 0603 SMD resistor. A quick search on eBay will find plenty.



[RROD!]

are you in the uk ??? also if you damaged the mobo so far just trying to do the install then not sure if you are upto smd soldering sorry i dont mean to sound rude just from the look of the repair that you tried to do not very good and them resistors are alot smaller?? again all i am saying is stop and make sure you are really upto the job before you go ahead and run the risk of making it worse



[matt2416]

are you in the uk ??? also if you damaged the mobo so far just trying to do the install then not sure if you are upto smd soldering sorry i dont mean to sound rude just from the look of the repair that you tried to do not very good and them resistors are alot smaller?? again all i am saying is stop and make sure you are really upto the job before you go ahead and run the risk of making it worse

No offence taken, yes I'm in the UK. I got the coolrunner working for a couple of weeks, then opened it and accidently pulled the pad off. Again, the shabby job is probalbly down to me doing it at like 3 in the morning lol.
