360_Multi_Builder_v0.7 on 11/12/2011
------------------------------------
- Added a default "launch.ini" to Flash when image is created with Dashlaunch.
Button_A=Hdd:\FSD\default.xex , default=Usb:\FSD\default.xex , rest=default
- Added the option to auto-build custom "launch.ini" per user preference.
Credits to xeBuild / Dashlaunch devs, especially cOz.
Credits to ir0nman for this usefull tool : "buildini.exe"
360_Multi_Builder_v0.6 on 10/12/2011
------------------------------------
- Removed the pre-patched RGH smc files that were used in version 0.5
- Now using xeBuild to patch the RGH/smc files for better RGH images compatibility.
360_Multi_Builder_v0.5 on 09/12/2011
------------------------------------
- Added Support for xeBuild and Dash version 14699
- Updated patches to Latest Dashlaunch v2.27 Patchset.
- now using xeBuild fcrt.bin extractor for Trinity images.
- Added RGH smc files for proper RGH image building.
- Added Xenon Retail Image build option.
360_Multi_Builder_v0.4 on 27/11/2011
------------------------------------
- Returned to using Dashlaunch v2.25 patch-set to avoid the "PlayDVD" problem.
with some Liteon Drives that requires the fcrt.bin for proper function.
- Fixed a bug in the Xell/Ecc script regarding Jaspers with CB version 6751.
360_Multi_Builder_v0.3 on 13/11/2011
------------------------------------
- Updated Dashlaunch patches to latest version 2.26 / thanks cOz
- Added the option to build the image without Dashlaunch patches too.
- Added the option to build the Jtag image with SMC = AUD_CLAMP.
- Added full checks of different CB versions to the Xell/ECC script.
- Added RawFlash v3 / "xenon.elf" to "Data" folder with flashing note.
- Fixed the Fans Speed back to auto (it was 70% in previous version).
360_Multi_Builder_v0.2 on 03/11/2011
------------------------------------
- Added Proper Support for Jasper with CB 6751 (where a donor CB 6750 will be used)
- Please note that Jasper with CB 6752 are not Glitchable even if the image was created
- Added Proper Support for Zephyr with CB 4578 (Program now supports both 4578 & 4579)
- Added a notification to the Python Script about the Falcon CB 5772 being not Glitchable
360_Multi_Builder_v0.1 on 31/10/2011
------------------------------------
- Updated "Easy ggBuilder" to "360 Multi Builder" with ECC/Jtag/Glitch & Retail image creation.
- Added Auto-Build ECC Glitch image "image_00000000.ecc" when "cpukey.txt" is missing.
- Added startup checks for "nanddump.bin" and "cpukey.txt" files existence.
- Jtag/Freeboot 13604 image creation with built-in Dashlaunch v2.25 patches & Xell-Reloaded.
- Glitch Hack 13604 image creation with built-in Dashlaunch v2.25 patches & Xell-Reloaded.
Easy ggbuild v0.4 Final on 26/10/2011
-------------------------------------
- Updated BestPig's fcrt_extractor to version 0.3
- Eliminated one step from the Trinity image creation for simpler operation
Easy ggbuild v0.3 on 25/10/2011
-------------------------------
- Added BestPig's fcrt_extractor which allows auto-extracting of "fcrt.bin/fcrt.bin.meta",
no more need for manual extracting of the 2 files using "360 Flash Dump Tool" for Trinity.
- The Program is now considered fully automated for all console types including Trinity.
Easy ggbuild v0.2 on 24/10/2011
-------------------------------
- Removed Xenon type from selection Menu
- Added Trinity notification about "fcrt.bin" and "fcrt.bin.meta" files needed for some Slim nands.
- Added 360 Flash Tool v0.97 to package with the ability to auto-launch it when needed.
- Added the option to build Dash 13604 Retail Images
- Added different menu selection checks to avoid wrong user input
---------- Post added at 16:18 ---------- Previous post was at 16:18 ----------
---------------------------------------------------------------
xeBuild v1.00.356
---------------------------------------------------------------
building glitch image
per build directory overridden from command line to 'my360'
data directory overridden from command line to '14699'
Using PATCHSMC option
file name overridden from command line to 'nandflash.bin'
------ parsing user ini at '.\my360\options.ini' ------
loading file...done!
pre-parsing and sanitizing
done!
User options.ini loaded, 0x14b bytes in memory
loading cpukey.txt from .\my360\cpukey.txt
CPU Key set to: 0xDA41F70EE5A8A686E5067196E9AAB2D8
setting 1blkey from ini: 0xDD88AD0C9ED669E7B56794FB68563EFA
1BL Key set to: 0xDD88AD0C9ED669E7B56794FB68563EFA sum: 0x983 (expects: 0x983)
xex Key set to: 0x20B185A59D28FDC340583FBB0896BF91 sum: 0x800 (expects: 0x800)
------ parsing ini at '.\14699\_glitch.ini' ------
ini version 14699
ini: label [jasperbl] found
found (1) 'cb_6750.bin' crc: 0xf7afa8cc
found (2) 'none' crc: 0x00000000
found (3) 'cd_8453.bin' crc: 0x25e0acd0
found (4) 'ce_1888.bin' crc: 0xff9b60df
found (5) 'cf_14699.bin' crc: 0x6fb4d90e
found (6) 'cg_14699.bin' crc: 0xbccc9fe1
ini: label [flashfs] found
found (1) 'aac.xexp' crc: 0x36790e61
found (2) 'bootanim.xex' crc: 0x187ede71
found (3) 'createprofile.xex' crc: 0x81d7a946
found (4) 'dash.xex' crc: 0x3957764c
found (5) 'deviceselector.xex' crc: 0x6246b4c0
found (6) 'gamerprofile.xex' crc: 0xb7add96a
found (7) 'hud.xex' crc: 0x202eb5c8
found (8) 'huduiskin.xex' crc: 0x4c80fbe9
found (9) 'mfgbootlauncher.xex' crc: 0x254ad664
found (10) 'minimediaplayer.xex' crc: 0xd8d21cfc
found (11) 'nomni.xexp' crc: 0xbf36fdf7
found (12) 'nomnifwk.xexp' crc: 0xa837ae53
found (13) 'nomnifwm.xexp' crc: 0x93246a8a
found (14) 'SegoeXbox-Light.xtt' crc: 0x086eb344
found (15) 'signin.xex' crc: 0xecd9cab1
found (16) 'updater.xex' crc: 0x125cdb94
found (17) 'vk.xex' crc: 0x9c744d4c
found (18) 'xam.xex' crc: 0x0b764b88
found (19) 'xenonclatin.xtt' crc: 0xd5d17ff5
found (20) 'xenonclatin.xttp' crc: 0x7a507ad1
found (21) 'xenonjklatin.xtt' crc: 0xdde4a14c
found (22) 'xenonjklatin.xttp' crc: 0x945b7092
found (23) 'ximecore.xex' crc: 0x8d45ea14
found (24) 'ximedic.xex' crc: 0x1d992bfb
found (25) 'ximedic.xexp' crc: 0xc90a651a
found (26) 'launch.xex' crc: 0x9f94f79b
found (27) 'lhelper.xex' crc: 0xeb581eb5
found (28) 'launch.ini' crc: 0x00000000
ini: label [security] found
found (1) 'crl.bin' crc: 0x00000000
found (2) 'dae.bin' crc: 0x00000000
found (3) 'extended.bin' crc: 0x00000000
found (4) 'secdata.bin' crc: 0x00000000
------ ini parsing completed ------
output name overridden to: nandflash.bin
------ Checking .\my360\nanddump.bin ------
Loading NAND dump (0x22ee70 bytes)...done!
NAND dump is from a big block machine
NAND dump uses big block controller
parsing dump into user and spare...
**************** WARNING *************************
nanddump.bin has NAND memory unit data, make
sure you back up any important data off the
internal MU before flashing a new image!
fbbuild will attempt to keep this data, but
many things could cause it to be invalid/corrupt.
****************************************************
done!
decrypting KeyVault at address 0x4000 of size 0x4000
keyvault decrypted OK, will use if no kv.bin is provided
decrypting SMC at address 0x1000 of size 0x3000
SMC decrypted OK, will use if no external smc.bin is provided
seeking smc config in dump...found at offset 0x3be0000! Using if no smc config is provided.
CF slot 0 decrypted ok LDV 0x03 Pairing: 0x5028b6
CF slot 1 decrypted ok LDV 0x02 Pairing: 0x5028b6
setting LDV from image to 3
setting pairing data from image to 0x5028b6
MobileB.dat found at page 0x1c000, size 2048 (0x800) bytes
MobileC.dat found at page 0x1c054, size 512 (0x200) bytes
MobileE.dat found at page 0x1c01c, size 1536 (0x600) bytes
seeking security files...fsroot found at page 0x16a00 raw offset 0x5a2a000
crl.bin found in sector 0x6d size 0xa00...verified! Will use if external file not found.
dae.bin found in sector 0x1b0 size 0x7090...verified! Will use if external file not found.
extended.bin found in sector 0x1b2 size 0x4000...verified! Will use if external file not found.
secdata.bin found in sector 0x6f size 0x400...verified! Will use if external file not found.
Writing initial header to flash image
------ Loading bootloaders and required security files ------
reading .\my360\smc.bin failed, using smc.bin from nand dump
reading .\my360\kv.bin failed, using kv.bin from nand dump
reading .\14699\cb_6750.bin (0x9a40 bytes)
reading .\14699\cd_8453.bin (0x5780 bytes)
reading .\14699\ce_1888.bin (0x5606a b pad 0x56070 b)
reading .\my360\xell-gggggg.bin (0x40000 bytes)
reading .\14699\cf_14699.bin (0x4450 bytes)
reading .\14699\cg_14699.bin (0x67168 b pad 0x67170 b)
reading .\14699\bin\patches_fat.bin (0x6f0 bytes)
reading .\my360\smc_config.bin failed, using smc_config.bin from nand dump
-------------------
checking smc_config
-------------------
extracting config
------------------
SMC config info:
------------------
Target temps: Cpu: 80øC Gpu: 75øC Edram: 77øC
Max temps : Cpu: 95øC Gpu: 90øC Edram: 92øC
Cpu Fan : (auto)
Gpu Fan : (auto)
MAC Address : 00:25:ae:66:99:1e
AVRegion : 0x00000200 (NTSC-J)
GameRegion : 0x01fc (NTSC/KOR)
DVDRegion : 3
resetKey : LLDX
---------------------
Checking for smc config data patches
smc config was not patched
---------------------
done!
------ Encrypting and finalizing bootloaders ------
SMC checksum: 5b3aed00
known clean SMC found, type: Jasper v4.1(2.03)
patching smc at offset: 0x12ba
SMC hacked successfully
done!
------ Adding bootloaders to flash image ------
adding smc.bin to 0x00001000 len 0x3000
adding kv.bin to 0x00004000 len 0x4000
adding cb_6750.bin to 0x00008000 len 0x9a40
adding none to 0x00011a40 len 0x0
adding cd_8453.bin to 0x00011a40 len 0x5a60
adding ce_1888.bin to 0x000174a0 len 0x56070
adding xell-gggggg.bin to 0x00070000 len 0x40000
adding cf_14699.bin to 0x000b0000 len 0x4450
adding cg_14699.bin to 0x000b4450 len 0x67170
adding patches_fat.bin to 0x000c0010 len 0x3e0
Writing CG patch slot overflow data to sysupdate.xexp1...done!
------ adding 28 firmware files ------
reading .\14699\aac.xexp (0x14000 bytes) (crc32: 0x36790e61 ini: 0x36790e61)
adding as aac.xexp1 at raw offset 0x2bdb5c0
reading .\14699\bootanim.xex (0x61000 bytes) (crc32: 0x187ede71 ini: 0x187ede71)
adding as bootanim.xex at raw offset 0x2bf0000
reading .\14699\createprofile.xex (0xc000 bytes) (crc32: 0x81d7a946 ini: 0x81d7a946)
adding as createprofile.xex at raw offset 0x2c51000
reading .\14699\dash.xex (0x63a000 bytes) (crc32: 0x3957764c ini: 0x3957764c)
adding as dash.xex at raw offset 0x2c60000
reading .\14699\deviceselector.xex (0x9000 bytes) (crc32: 0x6246b4c0 ini: 0x6246b4c0)
adding as deviceselector.xex at raw offset 0x329a000
reading .\14699\gamerprofile.xex (0x1b000 bytes) (crc32: 0xb7add96a ini: 0xb7add96a)
adding as gamerprofile.xex at raw offset 0x32a5000
reading .\14699\hud.xex (0x1e000 bytes) (crc32: 0x202eb5c8 ini: 0x202eb5c8)
adding as hud.xex at raw offset 0x32c3000
reading .\14699\huduiskin.xex (0x13000 bytes) (crc32: 0x4c80fbe9 ini: 0x4c80fbe9)
adding as huduiskin.xex at raw offset 0x32e2000
reading .\14699\mfgbootlauncher.xex (0x8000 bytes) (crc32: 0x254ad664 ini: 0x254ad664)
adding as mfgbootlauncher.xex at raw offset 0x32f7000
reading .\14699\minimediaplayer.xex (0xc000 bytes) (crc32: 0xd8d21cfc ini: 0xd8d21cfc)
adding as minimediaplayer.xex at raw offset 0x3300000
reading .\14699\nomni.xexp (0xe000 bytes) (crc32: 0xbf36fdf7 ini: 0xbf36fdf7)
adding as nomni.xexp1 at raw offset 0x330c000
reading .\14699\nomnifwk.xexp (0x2000 bytes) (crc32: 0xa837ae53 ini: 0xa837ae53)
adding as nomnifwk.xexp1 at raw offset 0x331a000
reading .\14699\nomnifwm.xexp (0x5000 bytes) (crc32: 0x93246a8a ini: 0x93246a8a)
adding as nomnifwm.xexp1 at raw offset 0x331e000
reading .\14699\SegoeXbox-Light.xtt (0x6000 bytes) (crc32: 0x086eb344 ini: 0x086eb344)
adding as SegoeXbox-Light.xtt at raw offset 0x3325000
reading .\14699\signin.xex (0x16000 bytes) (crc32: 0xecd9cab1 ini: 0xecd9cab1)
adding as signin.xex at raw offset 0x332e000
reading .\14699\updater.xex (0x7000 bytes) (crc32: 0x125cdb94 ini: 0x125cdb94)
adding as updater.xex at raw offset 0x3346000
reading .\14699\vk.xex (0x9000 bytes) (crc32: 0x9c744d4c ini: 0x9c744d4c)
adding as vk.xex at raw offset 0x334f000
reading .\14699\xam.xex (0x236000 bytes) (crc32: 0x0b764b88 ini: 0x0b764b88)
adding as xam.xex at raw offset 0x3359000
reading .\14699\xenonclatin.xtt (0x11b000 bytes) (crc32: 0xd5d17ff5 ini: 0xd5d17ff5)
adding as xenonclatin.xtt at raw offset 0x3592000
reading .\14699\xenonclatin.xttp (0x18000 bytes) (crc32: 0x7a507ad1 ini: 0x7a507ad1)
adding as xenonclatin.xttp1 at raw offset 0x36af000
reading .\14699\xenonjklatin.xtt (0x1a8000 bytes) (crc32: 0xdde4a14c ini: 0xdde4a14c)
adding as xenonjklatin.xtt at raw offset 0x36c8000
reading .\14699\xenonjklatin.xttp (0x7000 bytes) (crc32: 0x945b7092 ini: 0x945b7092)
adding as xenonjklatin.xttp1 at raw offset 0x3870000
reading .\14699\ximecore.xex (0x15000 bytes) (crc32: 0x8d45ea14 ini: 0x8d45ea14)
adding as ximecore.xex at raw offset 0x3877000
reading .\14699\ximedic.xex (0x90000 bytes) (crc32: 0x1d992bfb ini: 0x1d992bfb)
adding as ximedic.xex at raw offset 0x388d000
reading .\14699\ximedic.xexp (0x2800 bytes) (crc32: 0xc90a651a ini: 0xc90a651a)
adding as ximedic.xexp1 at raw offset 0x3920000
reading .\14699\launch.xex (0x9000 bytes) (crc32: 0x9f94f79b ini: 0x9f94f79b)
adding as launch.xex at raw offset 0x3922800
reading .\14699\lhelper.xex (0x6000 bytes) (crc32: 0xeb581eb5 ini: 0xeb581eb5)
adding as lhelper.xex at raw offset 0x392d000
reading .\14699\launch.ini (0x29e bytes)
adding as launch.ini at raw offset 0x3936000
------ adding 4 security files ------
reading .\my360\crl.bin (0xa00 bytes)
writing as crl.bin to flash
crl appears crypted, attempting to decrypt with CPU key...failed! Trying alternate key...success!
reading .\my360\dae.bin (0xad30 bytes)
writing as dae.bin to flash
dae appears encrypted, attempting to decrypt with CPU key...failed! Attempting to decrypt with alternate key...
success!
reading .\my360\extended.bin (0x4000 bytes)
writing as extended.bin to flash
reading .\my360\secdata.bin (0x400 bytes)
writing as secdata.bin to flash
------ checking for Mobile*.dat ------
MobileB.dat was found in dump, 0x800 bytes, adding type 0x31
MobileC.dat was found in dump, 0x200 bytes, adding type 0x32
MobileE.dat was found in dump, 0x600 bytes, adding type 0x34
------ adding smc_config.bin ------
adding smc config to offset 0x03be0000, len 0x400
------ finalizing image ------
Fixing up empty FS block entries...done!
Writing FS table to image...done!
fixing up big block LBA numbers in spare...done!
calculating ECD bytes and assembling raw image...done!
writing file 'nandflash.bin' to disk...done!
nandflash.bin written OK
---------------------------------------------------------------
nandflash.bin image built, info:
---------------------------------------------------------------
Console : Jasper (big block)
NAND size: 64MiB + NAND MU area
Build : Glitch
Xell : power on console with console eject button
CPU Key : DA41F70EE5A8A686E5067196E9AAB2D8
1BL Key : DD88AD0C9ED669E7B56794FB68563EFA
CF LDV : 3
---------------------------------------------------------------
xeBuild Finished. Have a nice day.
-------------------------------------------------------------
