Zephr Reset Glitch No Video on TV...

C

chopblock3xpert

Junior Member
Dec 4, 2011
21
0
Alright I am in need of help, I used FiB3R’s guide to do this glitch. I did the direct wire install of the Cool Runner. I read my original Nand about 4 times. I also compared them; they had no bad blocks what so ever. So I proceeded with the guide. I created my Xell/ecc glitch image I flashed that to the nand. I also flashed the reset glitch hack to the nand I follow the instructions of everything I did. I installed the cool runner. Now here is where I am having issues. My cool runner has a solid red light and the green led light flashes but my TV screen says no signal and I have everything connected. I need instructions so I don’t ruin my console since I don’t know what I would be doing past the guide that I am following. Any help would be greatly appreciated… Thanks in advance!

Information about my Console it’s a Zephyr HDMI console.

C

chopblock3xpert

Junior Member
Dec 4, 2011
21
0
I had it connected via Component cables. Before I read the Nand did I have to change the HDMI setting to component before I read the nand?

ball00

ball00

VIP Member
Nov 8, 2011
632
0
France
Is the console booting or is the coolrunner constantly remaining flashing and therefore not achieving the boot?

C

chopblock3xpert

Junior Member
Dec 4, 2011
21
0
I tried both component and HDMI... I think I found my problem the Orange wire connected to the point near the Hanna chip pulled the little pad when I placed the fan vent back on... The console doesn't power but the cool runner is on. Sucks for me looks like the console is done for!

D

d4rk_4ng3l

Junior Member
Feb 2, 2011
23
0
If STBY_CLK is broken then see these images, Credits to UberGeek.

Don't forget to Thank if anyone helped you a bit. ;)

M

morbidj

Full Member
Feb 24, 2004
39
0
DenCO
Now correct me if I am wrong but you will need to repair that trace before the console will boot, not easy but do able.. scrape the trace and solder to the left of the resistor and trace.

Sent from my 3VO using dual cores and 3D's

A

Aaronmaster69

Full Member
Jun 30, 2010
66
0
mendo
and if you mess up the resistor like i did them u can replace it with a 34 ohm resistor the old big kind. i used a 1/4 watt and it worked.

C

chopblock3xpert

Junior Member
Dec 4, 2011
21
0
Alright so I would like to update you all on what I have done. I took a box cutter and I

scrapped the trace. Then I applied flux to it, and I took a small piece of wire and cut it to

size and tinned the edges with solder. I then was able to solder it to the board and voila...

Console powers up. I then soldered a longer wire to the back of the console to an alternate

point and I have booted Xell. I am now going to buy a glue gun so I can make sure that

connection stays sealed without moisture or elements getting to it. I will also glue gun my

solder points as well, or do you guys object of doing that?

Now when I apply http://192.168.1.99/ it does absolutely nothing I am stuck on this part of

Fib3r's guide in my quest to doing the reset glitch on my first tutorial. I will make sure that I

take the time to "Thank" each one of you that is helping me along the way!

C

chopblock3xpert

Junior Member
Dec 4, 2011
21
0
Alright now I created my nandflash.bin and xenon.elf and

I saved them on to usb drive that I reformatted to Fat and

then to Fat 32. I have Booted Xell reloaded and when I

put in the USB it doesn't do anything. I am trying to use

the search feature for the past 30 mins or so and cant

really find a lot on this so thats why I am asking for help

here...

C

chopblock3xpert

Junior Member
Dec 4, 2011
21
0
OK I used another USB and it worked now I flashed the nand and turned off the console and

I also got my DVD key which was the reason I did the hack. Now when I boot up my Xbox

360, the green light on the cool runner doesn't glitch lol... This is starting to be a pain in the

ass! I almost have it now I just need it to boot then I can enjoy this console!
