RGH Zephyr not gliching

N

Naruto-007

Full Member
Aug 5, 2011
55
0
Puerto Rico
Hello again forum. SO i got my nand-x program the coolruner. Dump the nand. I check it with the nand-x healer and everything match. so i use J-tag tool create the ecc file and write it to the console. the console turns on but dosent boot no xell, nothing. So i go hajed and flash back the original nand. The xbox does boot fine. I try again every process and still no luck, i have repeat every process like 3 time, Also i have re solder everything such to make sure everything was ok. EDIT: coolruner light stays red it docent flash green UPDATE: i try to flash the stock nand again few time and now i get rrod with error code 0022
Here are some pic of the soldered board:



Last edited:
M

Mickey3177

VIP Member
Feb 2, 2011
301
0
Las Vegas USA
Where is that resistor going? is this something new :( Why don't you guys use the QSB, if you can't get them at all that's one thing but it just makes it much easier to solder that B point.

Try using 360 Multi Build .3 or 4 to create .ecc file, just try different tools, you need to find out if it's for sure wiring or flashing, I wouldn't rule out anything

Last edited:
N

Naruto-007

Full Member
Aug 5, 2011
55
0
Puerto Rico
Mickey3177 said:
Where is that resistor going? is this something new :( Why don't you guys use the QSB, if you can't get them at all that's one thing but it just makes it much easier to solder that B point.

Try using 360 Multi Build .3 or 4 to create .ecc file, just try different tools, you need to find out if it's for sure wiring or flashing, I wouldn't rule out anything
Click to expand...
Got a little problem now i flash back original again and now the xbox turns on but it docent boot

M

Mickey3177

VIP Member
Feb 2, 2011
301
0
Las Vegas USA
If you haven't changed your wiring, it's probably the the flash just rebuild it and install it the same way you did when it was working.

TIP: If you are just installing a Cool Runner, use tape to hold down your wire near the point, if it not working why use a butt load of hot glue if your not sure it's even going to work and DO NOT PUT HOT GLUE ON THE SOLDER POINT.

N

Naruto-007

Full Member
Aug 5, 2011
55
0
Puerto Rico
Mickey3177 said:
If you haven't changed your wiring, it's probably the the flash just rebuild it and install it the same way you did when it was working.

TIP: If you are just installing a Cool Runner, use tape to hold down your wire near the point, if it not working why use a butt load of hot glue if your not sure it's even going to work and DO NOT PUT HOT GLUE ON THE SOLDER POINT.
Click to expand...
Got a big problem now i flash ecc file and i re solder everythng and now i start the xbox and get rrod but now i have the code 0021 and i flash the original nand.and still get the same rrod :(

D

diaboliq20

VIP Member
Jun 23, 2011
3,497
0
Scotland
I have to say - that is some of the worst soldering I have ever seen - and most likely the cause of all of your issues - I don't mean to be rude man.....sorry.....
I know it seems like the stock answer, but really.....after you got to the point where you broke the QSB, you should have stopped......
I would STOP - contact someone who can look at it to see about repairing, but I would imagine, you are looking at a lot of trace work there....... and more than likely you will be better off buying a Falcon or Jasper

It looks like you have done a couple of ALT points have you?
also - what's witht he +3.3V?? is that solder or glue?

Last edited:
N

Naruto-007

Full Member
Aug 5, 2011
55
0
Puerto Rico
diaboliq20 said:
I have to say - that is some of the worst soldering I have ever seen - and most likely the cause of all of your issues - I don't mean to be rude man.....sorry.....
I know it seems like the stock answer, but really.....after you got to the point where you broke the QSB, you should have stopped......
I would STOP - contact someone who can look at it to see about repairing, but I would imagine, you are looking at a lot of trace work there....... and more than likely you will be better off buying a Falcon or Jasper

It looks laike you have one a couple of ALT points have you?
also - what's witht he +3.3V?? is that solder or glue?
Click to expand...
Lol yeah i know my solderin skill are bad. Thats glue on the 3v3.

D

diaboliq20

VIP Member
Jun 23, 2011
3,497
0
Scotland
:eek2: aaawww man - never glue a solder joint........that's gonna be a nightmare to fix buddy - it's gonna need stripping back to the bare bones, and checked for all the damaged points - and then fixed by re-soldering (to alt points where needed) and then rechecked.....getting the glue off to get to the solder will be a killer now - I would invest in a new one lol - already glitched lol
